Gardena 8893-U Cordless Lithium-Ion Grass Shears Instruction Manual

1. Introduzione

Thank you for choosing the Gardena 8893-U 3-Inch Cordless Lithium-Ion Grass Shears. This manual provides essential information for the safe and efficient operation, maintenance, and care of your new tool. Please read these instructions carefully before first use and keep them for future reference.

The Gardena 8893-U is designed for easy, cord-free cutting of lawn edges and for shaping boxwood plants. Its ergonomic design ensures comfortable handling during use.

2. Informazioni sulla sicurezza

AVVERTENZA: leggere tutte le avvertenze di sicurezza, le istruzioni, le illustrazioni e le specifiche fornite con questo utensile elettrico. La mancata osservanza di tutte le istruzioni elencate di seguito può causare scosse elettriche, incendi e/o lesioni gravi.

• Always wear appropriate personal protective equipment, including safety glasses, gloves, and sturdy footwear, when operating the shears.
• Keep hands and feet away from the blade area during operation.
• Do not operate the shears in wet conditions or near flammable liquids or gases.
• Ensure the battery is fully charged before use and only use the charger supplied by Gardena.
• Conservare l'utensile in un luogo asciutto e sicuro, fuori dalla portata dei bambini.
• Before cleaning or performing maintenance, ensure the tool is switched off and the battery is removed.
• Questo prodotto contiene sostanze chimiche note allo Stato della California come causa di cancro e malformazioni congenite o altri danni all'apparato riproduttivo.

3. Contenuto della confezione

Verificare che tutti gli articoli siano presenti al momento del disimballaggio:

• Gardena 8893-U Cordless Lithium-Ion Grass Shears
• Grass Blade (3-inch / 8 cm cutting width)
• Copertura di protezione della lama
• Caricabatterie
• Lithium-Ion Batteries (x2)
• Manuale di istruzioni

4. Prodotto finitoview

Familiarize yourself with the components of your Gardena Grass Shears:

• Interruttore di alimentazione: Pulsante On/Off.
• Blocco di sicurezza: Previene l'attivazione accidentale.
• Maniglia ergonomica: Designed for comfortable grip.
• LED Battery Status Display: Indicates charge level.
• Pulsante di rilascio della lama: For quick blade changes.
• Filo d'erba: 3-inch (8 cm) cutting width.
• Porta di ricarica: Per collegare il caricabatterie.

5. Impostazione

5.1 Caricamento della batteria

1. Ensure the grass shears are switched off.
2. Connect the charger to the charging port on the shears.
3. Collegare il caricabatterie a una presa elettrica standard.
4. The LED battery status display will indicate charging progress. A full charge takes approximately 6 hours.
5. Once fully charged, disconnect the charger. The operating time is approximately 90 minutes on a full charge.

5.2 Montaggio/sostituzione delle lame

The Gardena 8893-U features an innovative blade change system that requires no tools.

1. Ensure the shears are switched off and the battery is charged.
2. Press the blade release button (refer to Product Overview, punto 5).
3. Carefully slide the current blade out.
4. Insert the desired blade (e.g., grass blade or optional shrub blade) until it clicks securely into place.
5. Always attach the blade protection cover when the tool is not in use.

The shears can be adapted with optional blades: Model 2340 (3" Grass Shears) or Model 2343 (7" Shrub Shears).

6. Istruzioni per l'uso

6.1 Starting the Shears

1. Remove the blade protection cover.
2. Tieni premuto il pulsante del blocco di sicurezza.
3. While holding the safety lock, press the power switch to start the shears.
4. Release the safety lock button once the shears are running.

6.2 Cutting Grass Edges

• Hold the shears firmly with both hands if necessary, ensuring a comfortable and stable grip.
• Guide the blade along the lawn edge, maintaining a steady pace.
• Allow the blade to cut without forcing the tool.
• For best results, cut when the grass is dry.

6.3 Shaping Boxwood Plants

• Use precise, controlled movements to shape the plant.
• Work in small sections to achieve the desired form.
• Regularly clear cut material from the blades to maintain cutting efficiency.

6.4 Stopping the Shears

To stop the shears, simply release the power switch.

6.5 Video operativo

7. Manutenzione

Regular maintenance ensures the longevity and optimal performance of your Gardena Grass Shears.

7.1 Pulizia

1. Always switch off the shears and remove the battery before cleaning.
2. Use a brush or cloth to remove grass clippings and debris from the blades and housing.
3. Non utilizzare acqua o prodotti chimici aggressivi per pulire i componenti elettrici.
4. Lightly oil the blades after each use to prevent rust and ensure smooth operation.

7.2 Conservazione

• Store the shears with the blade protection cover attached.
• Keep the tool in a dry, frost-free environment.
• Ensure the battery is partially charged (not fully depleted or fully charged for long-term storage) if storing for extended periods.

8. Risoluzione Dei Problemi

9. Specifiche

10. Garanzia

The Gardena 8893-U Cordless Lithium-Ion Grass Shears come with a Garanzia del produttore di 2 anni. This warranty covers defects in materials and workmanship under normal use. Please retain your proof of purchase for warranty claims. For full warranty terms and conditions, please refer to the official Gardena websito o contattare l'assistenza clienti.

11. Assistenza clienti

For technical assistance, spare parts, or further information regarding your Gardena product, please contact Gardena Customer Service:

• Websito: Visit the official Gardena websito per FAQ e risorse di supporto.
• Telefono: Refer to your regional Gardena contact information for phone support.
• Negozio online: Negozio Gardena su Amazon

When contacting support, please have your model number (8893-U) and purchase date available.
