XREXS Extra Large Digital Wall Clock User Manual

Introduzione

Grazie per l'acquistoasing the XREXS Extra Large Digital Wall Clock. This clock is designed to provide clear, easy-to-read time, date, and temperature information, along with convenient alarm and timer functions. Its large display and versatile placement options make it suitable for various environments, including living rooms, offices, and classrooms. Please read this manual carefully to ensure proper setup and operation.

Informazioni sulla sicurezza

• Tenere il dispositivo lontano dall'acqua e da ambienti ad alta umidità.
• Non esporre l'orologio alla luce solare diretta o a temperature estreme.
• Use only the specified battery types (4 x AA and 2 x AAA batteries).
• Non mischiare batterie vecchie e nuove o diversi tipi di batterie.
• Smaltire le batterie usate in modo responsabile secondo le normative locali.
• Non tentare di smontare o riparare l'orologio da soli. Contattare personale qualificato per l'assistenza.

Contenuto della confezione

• 1 x XREXS Extra Large Digital Wall Clock
• 4 batterie AA
• 2 batterie AAA
• 1 x Manuale utente

Prodotto finitoview

Familiarize yourself with the main components of your XREXS Digital Wall Clock:

Figura 1: Davanti view of the XREXS Extra Large Digital Wall Clock. This image displays the large digital time, day of the week, date, and month, providing a clear overview of the clock's primary display.

Figura 2: Indietro view of the clock, illustrating the battery compartments for 4 AA and 2 AAA batteries, the two keyhole mounting slots for wall hanging, and the integrated fold-out stand for desk placement. This image helps identify the physical features for setup.

• Ampio display LCD: Shows time, date, day, and temperature.
• Pulsanti di controllo: Located on the back for setting time, alarm, timer, and display modes.
• Scomparti batteria: For 4 AA batteries (main power) and 2 AAA batteries (for memory backup).
• Fori di montaggio a parete: Two keyhole slots for easy wall installation.
• Supporto pieghevole: For stable placement on a desk or table.

Impostare

1. Installazione della batteria

1. Open the battery compartments on the back of the clock.
2. Insert 4 AA batteries into the main compartment, ensuring correct polarity (+/-).
3. Insert 2 AAA batteries into the smaller compartment, ensuring correct polarity (+/-). These batteries provide memory backup for settings during main battery changes.
4. Chiudere saldamente i vani batteria.

2. Opzioni di posizionamento

Figura 3: Illustration of the clock's versatility, showing it mounted on a wall above a television and standing on a desk. This highlights the two primary placement methods: using the keyhole slots for wall hanging or the fold-out stand for tabletop use.

• Montaggio a parete: Use the two keyhole slots on the back of the clock to hang it on screws or nails securely fastened to a wall. Ensure the mounting surface is stable.
• Posizionamento scrivania/tavolo: Extend the fold-out stand located on the back of the clock to place it upright on any flat surface.

Istruzioni per l'uso

1. Impostazione di ora e data

1. Premere il tasto IMPOSTATO button to enter setting mode. The first digit will flash.
2. Utilizzare il UP or GIÙ pulsanti per regolare il valore.
3. Premere IMPOSTATO again to confirm and move to the next setting (Hour → Minute → Year → Month → Day).
4. Dopo aver impostato il giorno, premere IMPOSTATO per uscire dalla modalità di impostazione.

2. Formato 12/24 ore

Figura 4: This image demonstrates the difference between the 12-hour (AM/PM) and 24-hour time formats on the clock's display, showing how the time presentation changes based on user selection.

In time display mode, press the UP button to switch between 12-hour (with AM/PM indicator) and 24-hour formats.

3. Temperature Display (℃/℉)

In time display mode, press the GIÙ button to switch between Celsius (℃) and Fahrenheit (℉) temperature units.

4. Modalità di visualizzazione

Figura 5: This graphic illustrates the three available display modes: Day+Date, Date+Temperature with automatic 5-second switching, and Day+Temperature. It visually explains how the clock can show different combinations of information.

The clock supports three display modes:

• DP-1 (Default): Time, Day, and Date are displayed.
• DP-2: Time and Day are displayed, with Date and Temperature automatically switching every 5 seconds.
• DP-3: Time, Day, and Temperature are displayed.

To cycle through display modes, press the MODALITÀ pulsante.

5. Funzione di allarme

Figura 6: This image highlights the 5-minute snooze function, activated by pressing the SNOOZE button, and also indicates that pressing any other button will turn off the alarm. It provides clear instructions for managing the alarm sound.

Figura 7: This graphic illustrates the three distinct alarm modes: 'Every Day Alarm', 'Monday to Friday Alarm', and 'Weekend Alarm'. It helps users understand how to set the alarm to ring on specific days of the week.

1. Premere il tasto SET ALLARME pulsante per accedere alla modalità di impostazione della sveglia.
2. Utilizzo UP or GIÙ to set the alarm hour and minute.
3. Premere SET ALLARME per confermare.
4. Cycle through alarm modes: Every Day Alarm, Monday to Friday Alarm, Weekend Alarm. Select your desired mode.
5. Per attivare/disattivare l'allarme, premere il tasto ALLARME ON / OFF pulsante. Un'icona di allarme apparirà/scomparirà sul display.
6. Quando suona la sveglia, premere il tasto POSTICIPARE button for a 5-minute snooze. Press any other button to turn off the alarm.

6. Count Up/Down Timer

Figura 8: This image showcases the clock's multifunctionality by displaying its Timer, standard Clock, and Alarm Clock modes. It visually confirms the presence of these three distinct operational states.

1. Premere il tasto TIMER button to enter timer mode.
2. Setting Countdown: Utilizzo UP or GIÙ per impostare le ore, i minuti e i secondi desiderati. Premere TIMER per spostarsi tra i campi.
3. Premere AVVIO/ARRESTO to begin the countdown. Press again to pause/resume.
4. When the countdown ends, the clock will sound an alarm for 90 seconds.
5. Conto alla rovescia: From the timer display, press AVVIO/ARRESTO without setting a time to begin counting up from zero.
6. Premere CHIARO per azzerare il timer.

7. Funzione di retroilluminazione

Figura 9: This image illustrates the clock's auto backlight feature, showing how the display brightness adjusts between two levels in dark conditions. It emphasizes the high contrast digits and the absence of glare for undisturbed sleep.

The clock features a smart backlight with two adjustable brightness modes:

• Regolazione automatica: The backlight brightness will automatically adjust based on ambient light conditions.
• Luminosità costante: You can set the backlight to a constant brightness level.

Refer to the specific button on the back of the clock labeled RETROILLUMINAZIONE or similar to cycle through these settings.

Manutenzione

• Pulizia: Pulire la superficie dell'orologio con un panno morbido e asciutto. Non utilizzare detergenti abrasivi o solventi.
• Sostituzione della batteria: When the display dims or functions become erratic, replace all batteries (both AA and AAA) with new ones. The AAA batteries will preserve your settings during the main battery change.
• Magazzinaggio: Se si conserva l'orologio per un periodo prolungato, rimuovere tutte le batterie per evitare perdite.

Risoluzione dei problemi

Specifiche

Garanzia e supporto

XREXS products are manufactured to high quality standards. For any questions, technical support, or warranty claims, please refer to the contact information provided with your purchase or visit the official XREXS websito. Si prega di conservare la prova d'acquisto ai fini della garanzia.
