KTS Laser Therapy Wrist Device User Manual

1. Introduzione

The KTS Semiconductor Laser Treatment Instrument is designed to provide low-intensity 650nm laser irradiation to acupuncture points. This process aims to reduce blood viscosity through photochemical reactions, thereby improving hemodynamics, blood lipid levels, blood sugar metabolism, and oxygen transport capacity. Additionally, surface irradiation of the nasal mucosa can enhance local blood circulation within the nasal cavity and improve the immune function of the nasal mucosa, assisting in the treatment of rhinitis and nasal congestion.

This device is suitable for the auxiliary treatment of various conditions, including hypertension, hyperviscosity, hyperlipidemia, hyperglycemia, ischemic cardiovascular, and cerebrovascular diseases, as well as rhinitis.

Figure 1: KTS Laser Therapy Wrist Device with included nasal probe and accessories.

2. Prodotto finitoview e componenti

Familiarize yourself with the main components and their functions to ensure proper operation.

Figure 2: Labeled components of the KTS Laser Therapy Wrist Device.

• Nasal Laser Irradiation Port: Connects the nasal probe for rhinitis treatment.
• Wrist Laser Irradiation Points: Multiple laser emitters on the underside for wrist treatment.
• Schermo di visualizzazione: Shows time, power level, and mode indicators.
• Pulsante Tempo: Regola la durata del trattamento.
• Pulsante di accensione: Adjusts laser intensity.
• Interruttore: Toggles between wrist mode, nasal mode, or both.
• Pulsante On/Off: Powers the device on/off and starts/stops treatment.
• Charger/Laser Jack: USB Type-C port for charging and connecting external laser probes.

3. Impostazione

3.1 Carica iniziale

Before first use, ensure the device is fully charged. Connect the provided USB Type-C charging cable to the device's charger/laser jack and a suitable power source. The device is rechargeable and designed for portability.

3.2 Posizionamento del dispositivo

For wrist treatment, it is recommended to wear the device on your left wrist. This placement ensures that the laser energy accurately traverses the radial artery, ulnar artery, Neiguan, and Daling acupoints for effective radiation treatment.

Figure 3: Correct placement of the device on the left wrist.

For nasal treatment, insert the nasal probe gently into your nostrils. Ensure a comfortable fit.

4. Istruzioni per l'uso

4.1 Passaggi operativi di base

1. Accensione: Premere a lungo il tasto Acceso/Spento pulsante per avviare il dispositivo.
2. Imposta ora: Fare clic sul Tempo button to adjust the usage time. The maximum setting is 60 minutes.
3. Regola intensità: Fare clic sul Energia button to adjust the light intensity.
4. Seleziona modalità: Fare clic sul Interruttore button to select the desired treatment mode: wrist mode, nasal mode, or both modes simultaneously.
5. Inizia il trattamento: Fare clic sul Acceso/Spento button again to begin the treatment.
6. Spegni: Premere a lungo il tasto Acceso/Spento button to turn off the device after treatment.

4.2 Raccomandazioni per l'uso

It is recommended to use this device twice daily, once in the morning and once in the evening. Each session should last between 30 to 60 minutes. Consistent use is key for effective results. Noticeable changes typically occur after approximately one month of regular use.

Figure 4: The device supports wrist, nasal, and combined treatment modes.

5. Manutenzione

Proper maintenance ensures the longevity and optimal performance of your KTS Laser Therapy Wrist Device.

• Pulizia: Wipe the device and probes with a soft, dry cloth after each use. Do not use abrasive cleaners or immerse the device in water.
• Magazzinaggio: Conservare il dispositivo in un luogo fresco e asciutto, lontano dalla luce solare diretta e da temperature estreme. Tenere fuori dalla portata dei bambini.
• Cura della batteria: To preserve battery life, avoid fully discharging the device frequently. Charge it regularly, even if not in active use for extended periods.

6. Risoluzione Dei Problemi

Se riscontri problemi con il tuo dispositivo, consulta i seguenti suggerimenti comuni per la risoluzione dei problemi:

• Il dispositivo non si accende: Assicurati che il dispositivo sia completamente carico. Collegalo al caricabatterie e attendi qualche minuto prima di riprovare ad accenderlo.
• Laser not emitting light: Check if the device is powered on and the treatment has been initiated. Verify that the correct mode (wrist or nasal) is selected.
• Schermo non funzionante: Try restarting the device by long-pressing the On/Off button. If the issue persists, ensure the battery is charged.
• No perceived effect: Ensure consistent and correct usage as per the recommendations in Section 4.2. Results may vary and typically require consistent use over several weeks.

If the problem persists after attempting these steps, please contact KTS customer support for further assistance.

7. Specifiche

8. Garanzia e supporto

For any warranty claims, technical support, or inquiries regarding your KTS Laser Therapy Wrist Device, please contact the seller directly. The seller, KTS Official, can provide assistance with product-related issues and support.

Conservare la prova d'acquisto per eventuali richieste relative alla garanzia.
