1. Introduzione
Thank you for choosing the Byecold Infrared Ceiling Heater with Thermostat and LED Light. This manual provides essential information for the safe and efficient operation of your new heater. Please read it thoroughly before installation and use, and retain it for future reference.
This infrared heater provides comfortable warmth similar to sunlight, without CO2 emissions, contributing to a clean and dust-free environment. It features integrated LED lighting with adjustable color temperature and brightness, all controllable via the included remote thermostat.
Image 1.1: The Byecold Infrared Ceiling Heater with its remote control, installed on a ceiling.
2. Informazioni sulla sicurezza
AVVERTENZA: per ridurre il rischio di incendi, scosse elettriche o lesioni, leggere e comprendere tutte le istruzioni prima di utilizzare questo prodotto.
- Always ensure the heater is properly installed and securely mounted according to the instructions.
- Non utilizzare il riscaldatore se il cavo o la spina sono danneggiati, oppure se il riscaldatore non funziona correttamente, è caduto o è stato danneggiato in qualsiasi modo.
- Tenere materiali combustibili, come mobili, cuscini, biancheria da letto, carta, vestiti e tende ad almeno 1 metro (3 piedi) dalla parte anteriore della stufa.
- This heater is equipped with an overheating protection system that automatically cuts off power if the internal temperature exceeds safe limits. If this occurs, disconnect the power, allow the unit to cool, and then reconnect. If the issue persists, contact support.
- Do not use in bathrooms or other wet locations unless specifically rated for such environments. This model features waterproof LED light, but general electrical safety precautions apply.
- Garantire l'alimentazione voltage corrisponde alla potenza nominale indicata sull'etichetta del riscaldatore.
Image 2.1: Diagram illustrating the overheat protection feature, which automatically cuts off power when the unit overheats.
Image 2.2: Icons indicating waterproof design and electrical safety features, suitable for various indoor environments.
3. Contenuto della confezione
Dopo aver disimballato, verificare che tutti gli articoli elencati di seguito siano presenti e integri:
- 1 x Byecold Infrared Ceiling Heater
- 1 x Thermostat Remote Control
- 1 set of Installation Accessories (screws, wall anchors)
- 1 x Manuale utente
4. Configurazione e installazione
The Byecold Infrared Ceiling Heater is designed for ceiling or wall mounting. Professional installation is recommended for electrical connections.
4.1 Montaggio del riscaldatore
The heater can be mounted on a ceiling or wall. Ensure the mounting surface is sturdy enough to support the heater's weight (approximately 8 kg). Refer to the included installation accessories for proper mounting.
Image 4.1: Diagram showing the dimensions of the heater: 1280mm (length) x 630mm (width) x 33mm (thickness).
Important Tip for Wall Anchors:
When using the provided two-part wall anchors (dübel), ensure the threaded piece is inserted into the wall first, with the threaded receiving end facing outwards. This prevents the shorter threaded part from detaching under load, which could cause the heater to fall. If unsure, consult a professional.
4.2 Collegamento elettrico
Connect the heater to a 230 VAC power source. It is recommended to have a qualified electrician perform the electrical wiring to ensure safety and compliance with local regulations.
4.3 Pairing the Heater and Thermostat Remote Control
Follow these steps to pair your heater with the remote control:
- Unplug the heater from the power outlet, then plug it back in. You will hear a short beep sound.
- Within 1 minute of plugging in the heater, simultaneously press and hold the MODALITÀ E C / F pulsanti sul telecomando.
- Continue holding until you hear a long beep sound. This indicates that the pairing process is complete.
Note: If pairing is not completed within 1 minute, unplug and re-plug the heater, then repeat the steps above.
Image 4.2: The heater and remote control, illustrating the pairing process. Key features highlighted include secure and easy pairing, no wiring required, separate control for heating and lighting functions.
5. Istruzioni per l'uso
The Byecold Infrared Ceiling Heater offers both heating and LED lighting functions, controlled by the supplied remote thermostat.
Image 5.1: Diagram of the remote control, detailing buttons for light operation (Brightness+, Light On/Off, Brightness-) and thermostat operation (LOCK, MODE, SET, TIME, FAV, C/F, Power, Temperature Up/Down).
5.1 Funzione Riscaldamento
The infrared technology heats objects and people directly, similar to sunlight, rather than heating the air. This results in a comfortable and consistent warmth.
- Accensione/spegnimento: Press the power button on the remote control to turn the heating function on or off.
- Impostazione della temperatura: Utilizzare il IMPOSTATO button and the up/down arrows to adjust the desired room temperature. The LCD screen on the remote will display the current room temperature and the set temperature.
- Selezione della modalità: Utilizzare il MODALITÀ button to cycle through different operating modes (e.g., comfort, economy, anti-freeze, program).
- Funzione timer: IL TEMPO button allows you to set a timer for automatic shutdown or scheduled operation.
- Tasto C/F: Alterna la visualizzazione della temperatura tra Celsius e Fahrenheit.
Image 5.2: Illustration of the far-infrared principle. It warms people and objects directly, providing gentle and pleasant heat without significantly heating the air, similar to how sunlight works.
Image 5.3: A person and a dog relaxing under the infrared heater, demonstrating the comfortable and direct warmth provided.
5.2 Funzione di illuminazione a LED
La luce LED integrata offre temperatura di colore e luminosità regolabili.
- Luce accesa/spenta: Press the light power button on the remote control to turn the LED light on or off.
- Regolazione della luminosità: Utilizzare il Luminosità+ E Luminosità- pulsanti per aumentare o diminuire l'intensità luminosa.
- Temperatura del colore: The LED light can switch between cool white (6000K) and warm white (3000K). Refer to the remote control for specific buttons to adjust color temperature.
Image 5.4: Visual representation of the LED light options, showing warm light (3000K) and white light (6000K), along with brightness levels from 10% to 100%.
Note: Both heating and lighting functions are exclusively controlled by the supplied remote control and cannot be operated via standard wall switches.
Image 5.5: The heater with its remote control, emphasizing that heating and lighting functions are controlled solely by the remote, not by wall switches.
6. Manutenzione
Una manutenzione regolare garantisce prestazioni ottimali e longevità del riscaldatore.
- Scollegare sempre l'alimentazione elettrica prima di effettuare operazioni di pulizia o manutenzione.
- Pulire le superfici esterne con un panno morbido, damp panno. Non utilizzare detergenti abrasivi o solventi, poiché potrebbero danneggiare la finitura.
- Ensure the heater is completely dry before reconnecting to power.
- Non tentare di aprire o riparare autonomamente la stufa. Per qualsiasi intervento di manutenzione, rivolgersi a personale qualificato.
7. Risoluzione Dei Problemi
If you encounter issues with your Byecold heater, refer to the following common problems and solutions:
| Problema | Possibile causa | Soluzione |
|---|---|---|
| Il riscaldatore non si accende. | No power supply; remote control not paired; remote control batteries low. | Check power connection; re-pair remote control (Section 4.3); replace remote control batteries. |
| Nessuna emissione di calore o calore insufficiente. | Thermostat set too low; room size too large for heater wattage; heater in standby mode. | Aumentare la temperatura impostata; assicurarsi che il riscaldatore sia caldotage is appropriate for the room; check remote display for active heating mode. Note that infrared heats objects directly, not air, so ambient air temperature may not rise quickly. |
| La luce LED non funziona. | Light function off; remote control issue. | Press the light power button on the remote; check remote batteries. |
| Il riscaldamento si spegne inaspettatamente. | Overheating protection activated; timer function set. | Disconnect power, allow to cool, then reconnect. Check if a timer was set for automatic shutdown. |
If the problem persists after trying these solutions, please contact Byecold customer support.
8. Specifiche
| Caratteristica | Specificazione |
|---|---|
| Marca | Ciao |
| Numero di modello | 3H1206L-TH |
| Potenza in uscita | 800W (as per title, specification says 840W, using 800W for consistency with title) |
| Dimensioni (L x P x A) | Dimensioni: 128 cm x 63 cm x 3.3 cm |
| Peso | 8 kg |
| Voltage | 230 V CA |
| Fonte di energia | Elettrico con cavo |
| Tipo di montaggio | Ceiling Mount / Wall Mount |
| Caratteristiche speciali | Programmable Thermostat, LED Lighting (Cool White/Warm White, adjustable brightness), Overheating Protection |
| Metodo di riscaldamento | Heat Radiation (Infrared) |
| Uso interno/esterno | Al chiuso |
9. Garanzia e supporto
Byecold is committed to product quality and customer satisfaction. All products undergo strict quality control before leaving the factory.
For any questions regarding your product, technical assistance, or warranty claims, please contact Byecold customer support. Our team is available to provide a prompt response within 24 hours.
For returns or replacements, a dedicated warehouse is set up to handle these issues efficiently.
Per i termini e le condizioni di garanzia specifici, fare riferimento alla documentazione di acquisto.
You can find more information and contact details on the official Byecold store: Byecold Store
