YESYAMO 3600 PTZ Solar Security Camera User Manual

1. Introduzione

Thank you for choosing the YESYAMO 3600 PTZ Solar Security Camera. This manual provides detailed instructions for the installation, operation, and maintenance of your new security camera. Please read this manual thoroughly before use to ensure proper functionality and to maximize the benefits of your device. This camera is designed for outdoor use, offering comprehensive surveillance with its 2K QHD resolution, 3600 pan/tilt capabilities, and solar-powered operation.

Figure 1.1: YESYAMO 3600 PTZ Solar Security Camera with Solar Panel

2. Prodotto finitoview

2.1 Cosa c'è nella scatola

• YESYAMO GX8S Solar Camera
• Pannello solare
• Cavo USB
• Flexible Support
• Manuale d'uso
• Base rimovibile
• Viti di montaggio

Figura 2.1: Contenuto della confezione

3. Caratteristiche principali

• Risoluzione 2K QHD: Advanced 2K (2304x1296) resolution with a color sensor provides superior image quality compared to 1080P, offering clearer and smoother visuals.
• Visione notturna a colori: Captures finer details even in low-light conditions, enhancing security and identification.
• PIR Human Detection & Triple Alert: Upgraded intelligent PIR infrared sensor accurately detects human contours, reducing false alarms. Upon detection, the camera activates lights, an alarm, and sends instant phone notifications (within 1 second). Two-way audio allows for direct communication.
• 3600 PTZ Functionality: Offers 3550 horizontal pan and 900 vertical tilt rotation for comprehensive surveillance without blind spots.
• 100% senza fili e alimentato a energia solare: Equipped with a large-capacity rechargeable battery and a solar panel for continuous, eco-friendly operation without frequent recharging.
• IP66 resistente alle intemperie: Designed to withstand various outdoor weather conditions, ensuring reliable performance year-round.
• Opzioni di archiviazione: Supports both local SD card storage (up to 128GB) and encrypted cloud storage for secure data management.
• Compatibilità con Alexa: Works with Alexa for convenient voice control and integration into smart home systems.

Figure 3.1: 2K QHD Resolution with 5X Digital Zoom

Figure 3.2: 3600 Coverage (3550 Pan & 900 Tilt)

Figura 3.3: Design resistente alle intemperie IP66

4. Configurazione e installazione

4.1 Installazione fisica

The camera and solar panel are designed for easy installation. Choose a location that provides optimal sunlight exposure for the solar panel and a clear view for the camera. The camera supports both wall-mounted and ceiling-mounted installations.

1. Scegli la posizione: Select a suitable outdoor location for the camera and solar panel. Ensure the solar panel receives direct sunlight for most of the day.
2. Montaggio: Use the provided mounting screws and flexible support to securely attach the camera and solar panel to the desired surface (wall or ceiling).
3. Collegare il pannello solare: Collegare il cavo del pannello solare alla porta di ricarica della fotocamera.

Figure 4.1: Installation Options (Wall-mounted & Ceiling-mounted)

Figura 4.2: Passaggi di installazione

4.2 Download e connessione dell'app

To operate your camera, you will need to download the companion mobile application. The camera works with 2.4Ghz WiFi networks for better coverage and penetration.

1. Scarica l'app: Cercare the 'Yes iH' app on the App Store (iOS) or Google Play Store (Android) and install it on your smartphone.
2. Creare un account: Apri l'app e segui le istruzioni sullo schermo per creare un nuovo account utente.
3. Aggiungi dispositivo: Power on the camera. In the app, select 'Add Device' and follow the prompts to connect your camera to your 2.4Ghz WiFi network. You may need to scan a QR code on the camera or enter account details.
4. Configurazione: Once connected, you can configure settings such as motion detection zones, alert preferences, and recording options within the app.

Figure 4.3: Download the Yes iH App

5. Istruzioni per l'uso

5.1 Vivere View e controllo PTZ

Access the live feed of your camera through the 'Yes iH' app. You can remotely control the camera's pan and tilt movements to view diverse aree.

• Apri l'app e seleziona la tua fotocamera dall'elenco dei dispositivi.
• The live video feed will appear. Use the on-screen controls to pan (3550) and tilt (900) the camera.

5.2 Audio bidirezionale

La telecamera è dotata di microfono e altoparlante integrati, consentendo la comunicazione bidirezionale.

• Mentre in diretta view, tocca l'icona del microfono per parlare attraverso la telecamera.
• Tocca l'icona dell'altoparlante per ascoltare l'audio proveniente dalla posizione della telecamera.

Figura 5.1: Comunicazione audio bidirezionale

5.3 Rilevamento del movimento e avvisi

The camera uses PIR human detection to minimize false alarms and provides instant alerts.

• Abilita rilevamento: In the app settings, ensure PIR Human Detection is enabled.
• Imposta zone di rilevamento: Definisci aree specifiche all'interno della telecamera view dove vuoi che venga rilevato il movimento.
• Impostazioni degli avvisi: Customize alert types (push notifications, siren, spotlight) and sensitivity levels.

Figure 5.2: AI Intelligent Human Detection

Figure 5.3: Triple Alert System

5.4 Registrazione e archiviazione

The camera supports both local storage via an SD card and cloud storage.

• Scheda SD: Inserire una scheda Micro SD (fino a 128 GB, non inclusa) nell'apposito slot sulla telecamera per la registrazione locale.
• Archiviazione cloud: The app offers cloud storage options, including a 7-day free trial. Your data is encrypted for privacy.
• Riproduzione: Accedi a foo registratotage from either the SD card or cloud via the app's history section.

Figura 5.4: Archiviazione su scheda Micro SD

Figure 5.5: Cloud Service (7-Day Free Trial)

6. Manutenzione

Una manutenzione regolare garantisce la longevità e le prestazioni ottimali della tua fotocamera.

• Pulizia del pannello solare: Pulire periodicamente il pannello solare con un panno morbido e asciutto.amp panno per rimuovere polvere, sporco o detriti che potrebbero compromettere l'efficienza della ricarica.
• Pulizia delle lenti: Pulisci delicatamente l'obiettivo della fotocamera con un panno in microfibra per garantire una qualità dell'immagine nitida. Evita materiali abrasivi.
• Aggiornamenti del firmware: Check the 'Yes iH' app regularly for firmware updates. Keeping your camera's firmware up-to-date ensures access to the latest features and security enhancements.
• Stato della batteria: While the solar panel provides continuous power, ensure the camera is installed in a location with sufficient sunlight to maintain battery charge, especially during prolonged cloudy periods.

Figure 6.1: Solar Panel Charging for Continuous Operation

7. Risoluzione Dei Problemi

8. Specifiche

9. Garanzia e supporto

The YESYAMO 3600 PTZ Solar Security Camera comes with a Garanzia di 2 anno, ensuring your peace of mind. We also provide supporto tecnico a vita per aiutarti con qualsiasi domanda o dubbio tu possa avere riguardo al tuo prodotto.

For technical assistance, warranty claims, or any other inquiries, please do not hesitate to contact our customer service team:

• E-mail: euservice@yesyamo.com

Our support team is available 24/7 to provide prompt and helpful solutions.
