Introduzione
Thank you for choosing the Irfora GT972 Metal Detector. This device is designed for detecting various metals, including coins, relics, jewelry, gold, and silver. It features high sensitivity and discrimination capabilities, making it versatile for different treasure hunting environments. This manual provides detailed instructions for assembly, operation, and maintenance to ensure optimal performance and longevity of your metal detector.
Contenuto della confezione
Please verify that all items listed below are present in your package.
- 1 x Irfora GT972 Metal Detector Unit
- 1 x Manuale utente (inglese)
- Note: 2 x 9V batteries are not included and must be purchased separately.
Caratteristiche principali
- Schermo LCD: Provides clear indications of metal types, signal strength, DISC and NOTCH settings, sensitivity levels, battery condition, and a digital display of the target ID.
- Three Audio Discrimination Tones: Emits distinct high, medium, and low tones to differentiate between various types of metal targets.
- NOTCH Function: Allows discrimination against unwanted metal types, enabling the user to focus on valuable items.
- DISC Function: Eliminates specific target categories by setting a DISC value. The detector will not respond to targets exceeding this numerical setting.
- PINPOINTER Function: Accurately locates the precise position of a detected target.
- Bobina di ricerca impermeabile: Equipped with a 10-inch round search coil that is waterproof for effective searching in shallow water.
Installazione e assemblaggio
Follow these steps to assemble your Irfora GT972 Metal Detector.
- Collegare la bobina di ricerca: Secure the 10-inch search coil to the lower stem using the provided bolt and nut. Ensure it is firmly attached but allows for slight angle adjustment.
- Collegare gli steli: Insert the lower stem into the middle stem, and then connect the middle stem to the upper stem. Adjust the length to a comfortable operating height.
Image: The metal detector showing its adjustable height feature. The left side shows the detector extended, and the right side shows it in a more compact form, indicating adjustability.
- Mount the Controller Unit: Slide the controller unit onto the upper stem. Ensure it is securely fastened.
Immagine: Un esploso view diagram illustrating the main components of the metal detector, including the search coil assembly, controller unit, adjustable height mechanism, and armrest stem.
- Installa le batterie: Open the battery compartment on the controller unit. Insert two 9V batteries, ensuring correct polarity. Close the compartment securely.
Immagine: un primo piano view of the metal detector's control unit, highlighting the battery compartment and explicitly stating that 2x 9V batteries are required and not included.
- Avvolgere il cavo: Carefully wrap the search coil cable around the stem, ensuring it is not too tight or loose, and connect the cable to the controller unit.
- Regola il bracciolo: Adjust the armrest to a comfortable position for prolonged use.
Istruzioni per l'uso
Accensione/spegnimento
- Press the Power button to turn the detector ON.
- Press and hold the Power button to turn the detector OFF.
Comprensione del display LCD
The LCD provides visual feedback on detected targets and current settings.
- Metal Types: Icons or indicators for different metal categories.
- Potenza del segnale: Bar graph indicating the strength of the detected signal.
- DISC/NOTCH Settings: Displays current discrimination and notch settings.
- SENS Level: Shows the current sensitivity level.
- Condizioni della batteria: Indica la durata residua della batteria.
- ID destinazione: A numerical value that helps identify the type of metal.
Immagine: Un dettaglio view of the metal detector's LCD screen, illustrating the various indicators for metal types, signal strength, DISC and NOTCH settings, sensitivity, battery status, and target ID.
Modalità operative e funzioni
The GT972 offers multiple operating modes to optimize your search.
- DISC (Discriminazione): Use this mode to eliminate unwanted targets. By setting a specific DISC value, the detector will ignore metals below that value. This is useful for filtering out junk metal.
- TACCA: The NOTCH function allows you to selectively accept or reject specific categories of metals. This is more precise than DISC for targeting or ignoring particular items.
- PINPOINTER: Once a target is detected, activate the PINPOINTER mode to narrow down its exact location. Move the coil slowly over the detected area until the signal is strongest and most stable.
- Audio Discrimination: The detector provides three distinct audio tones:
- Tono basso: Typically indicates ferrous metals or small, low-conductivity items.
- Tono medio: Often indicates medium-conductivity metals like some jewelry or older coins.
- Tono alto: Usually signifies high-conductivity metals such as silver or copper.
Image: The metal detector with an overlay highlighting its key features: 5 Operating Modes, 10-inch Waterproof Coil, Precise Positioning, and Type-C Interface.
Searching Techniques
- Sweep Pattern: Hold the search coil parallel to the ground and sweep it slowly from side to side in overlapping arcs.
- Altezza della bobina: Keep the search coil as close to the ground as possible without touching it.
- Water Searching: The 10-inch search coil is waterproof, allowing for detection in shallow water. Ensure the control unit remains dry.
Image: A close-up of the 10-inch round search coil partially submerged in water, demonstrating its waterproof capability for shallow water detection.
Image: A person operating the metal detector in a desert landscape. Insets show examples of items that can be detected, such as gold coins, detection cables, and items found at archaeological sites.
Image: A person using the metal detector in a green grassy area. Insets display different types of metals that can be found, including gold nuggets, rings, coins, and various relics.
Manutenzione e cura
- Pulizia: Pulisci il rilevatore con un annuncioamp panno dopo ogni utilizzo. Evitare detergenti abrasivi o solventi.
- Magazzinaggio: Conservare il rilevatore in un luogo fresco e asciutto quando non lo si utilizza. Rimuovere le batterie se lo si conserva per periodi prolungati per evitare perdite.
- Bobina di ricerca: La bobina di ricerca è impermeabile, ma l'unità di controllo non lo è. Evitare di immergere l'unità di controllo in acqua.
- Sostituzione della batteria: Sostituire le batterie quando sul display LCD compare l'indicatore di batteria scarica.
Risoluzione dei problemi
| Problema | Possibile causa | Soluzione |
|---|---|---|
| Nessun potere | Batterie scariche o installate in modo errato. | Sostituire le batterie con batterie nuove da 9 V, assicurandosi della corretta polarità. |
| Segnali irregolari o letture false | High sensitivity setting, electromagnetic interference, or mineralized ground. | Reduce sensitivity. Move away from power lines or other electronic devices. Perform ground balance if available (refer to advanced settings in full manual). |
| Il rilevatore non trova i bersagli | Incorrect discrimination settings, too low sensitivity, or target is too deep. | Adjust DISC/NOTCH settings to accept more metal types. Increase sensitivity. Sweep slower and closer to the ground. |
| Weak or no audio | Low battery, volume too low, or faulty headphones (if used). | Check battery level. Increase volume. Test with/without headphones. |
Specifiche
| Caratteristica | Dettaglio |
|---|---|
| Modello | La GT972 |
| Marca | Ifora |
| Materiale | addominali |
| Detected Metal Size (Example) | 18cm (for φ25mm US coin) |
| Alimentazione elettrica | 2 * 9V batteries (Not included) |
| Cerca bobina | 10-inch round, waterproof |
| Display | LCD with Target ID, DISC/NOTCH, SENS, Battery Indicator |
| Modalità operative | 5 modes (including DISC, NOTCH, PINPOINTER) |
| Toni audio | 3 distinct tones (Low, Medium, High) |
Video del prodotto
Non sono stati trovati video ufficiali del venditore per questo modello.
Garanzia e supporto
For warranty information and technical support, please refer to the documentation provided at the time of purchase or contact Irfora customer service directly. Specific warranty terms may vary by region and retailer.
