LIECTROUX HCR-10 Robotic Window Cleaner User Manual

1. Prodotto finitoview

The LIECTROUX HCR-10 is an intelligent robotic window cleaner designed for various glass surfaces. It features an integrated suction motor providing 2800Pa suction, a dual-spiral cleaning head, and microfiber cleaning cloths for effective vertical surface cleaning. This robot is suitable for cleaning windows, tiles, glass floors, and other hard-to-reach areas, including interior and exterior windows of high-rise buildings.

Image: LIECTROUX HCR-10 Robotic Window Cleaner, front view.

Caratteristiche principali:

• Aspirazione potente: Integrated motor provides 2800Pa suction for secure adhesion to surfaces.
• Spruzzo d'acqua ad ultrasuoni: Features an ultrasonic water spray system for effective dirt and stain softening.
• AI Routing: Intelligent AI technology detects window frames and obstacles, automatically adjusting its cleaning path.
• Molteplici modalità di pulizia: Offers 3 automatic cleaning modes for comprehensive coverage.
• Caratteristiche di sicurezza: Equipped with an Uninterrupted Power System (UPS) battery for 25 minutes of backup power during outages and a 4-meter safety rope.
• Telecomando: Allows for convenient control of the cleaning process.
• Motore Brushless: Utilizes a Japanese brushless motor for efficient and quiet operation.

2. Importanti istruzioni di sicurezza

Please read and understand all safety instructions before operating the LIECTROUX HCR-10 Robotic Window Cleaner. Failure to follow these instructions may result in electric shock, fire, or serious injury.

Image: Safety warning label. Note: While the image displays 'Model No.: HCR-09', these safety guidelines are generally applicable to similar robotic window cleaners, including the HCR-10.

1. Prima dell'uso leggere sempre attentamente il manuale di istruzioni.
2. Prima di ogni utilizzo, fasten the safety rope securely and tie it to a sturdy house fixture.
3. Sempre remove the machine from the surface first prima di spegnere l'alimentazione.
4. Do not use the robot on glass doors or windows without frames, as it may lose suction and fall.
5. Questo apparecchio non è destinato all'uso da parte dei bambini. Tenere fuori dalla portata dei bambini.
6. Assicurarsi che il cavo di alimentazione sia collegato saldamente e non danneggiato.
7. Non utilizzare il robot in condizioni di pioggia o di umidità estrema.
8. Non utilizzare il robot su superfici in vetro rotte o danneggiate.

3. Contenuto della confezione

Verificare che tutti i componenti siano presenti nella confezione:

• LIECTROUX HCR-10 Robotic Window Cleaner
• Telecomando
• Microfiber Cleaning Cloths (multiple)
• Power Adapter and Cable (approx. 5.2m total length)
• Safety Rope (approx. 4m length)
• Manuale d'uso

4. Istruzioni per l'installazione

4.1 Fissaggio della fune di sicurezza

Before each use, attach the safety rope to the designated anchor point on the robot. Secure the other end of the safety rope to a strong, fixed object indoors, such as a heavy piece of furniture or a window frame anchor point. This is crucial to prevent the robot from falling in case of power loss or suction failure.

4.2 Collegamento dell'alimentazione

Connect the power adapter to the robot and then plug it into a power outlet. The robot operates primarily via a wired connection. The integrated UPS battery provides backup power for approximately 25 minutes in case of a power outage, allowing you to safely retrieve the robot.

Image: Power connection and safety rope setup. Shows 20 minutes power outage protection, 4m safety rope, and 1.5m power cable segment.

4.3 Applicazione dei panni per la pulizia

Attach the clean microfiber cloths to the cleaning pads on the underside of the robot. Ensure they are securely fastened and cover the entire cleaning surface.

4.4 Riempimento del serbatoio dell'acqua

Locate the water tank inlet on the robot. Carefully fill the 30ml water tank with clean water or a recommended window cleaning solution (not included). Do not overfill. The ultrasonic spray function requires water for effective cleaning.

5. Istruzioni per l'uso

5.1 Preparazione della superficie

Ensure the glass surface is free from large debris or loose particles that could scratch the glass or interfere with the robot's movement.

5.2 Placing the Robot

With the power connected and the safety rope secured, place the robot onto the glass surface. Press the power button on the robot or the remote control. The robot will activate its suction motor and adhere to the surface.

5.3 Inizio della pulizia

The LIECTROUX HCR-10 offers three automatic cleaning modes and can be controlled via the remote control.

• Modalità di pulizia automatica: The robot uses intelligent AI technology to detect window frames and obstacles, planning an optimal cleaning path. You can select from different automatic patterns (e.g., up-down, left-right, right-left) using the remote control.
• Controllo manuale: Utilizzare i pulsanti direzionali sul telecomando per guidare manualmente il robot per la pulizia di punti specifici o di aree specifiche.
• Spruzzo d'acqua ad ultrasuoni: The robot will automatically spray water during the cleaning cycle to soften dirt and stains. This feature can also be activated manually via the remote control if available.

Image: Ultrasonic water spray for effective dust removal.

Image: Cleaning process steps: Suction (2800Pa vacuum), Wiping (removes floating dust), Spraying (water spray to soften dirt), Wiping (removes dirt and water stains).

Image: Cleaning paths (Up-down, Left-right, Right-left) and remote control.

5.4 Applicable Surfaces

The HCR-10 is compatible with various smooth, vertical surfaces:

• Glass windows (framed and unframed, but exercise caution with unframed as per safety warnings)
• Bathroom mirrors
• Superfici piastrellate
• Pareti di marmo
• Porte in vetro

Immagine: Examples of applicable surfaces including bathroom mirrors, wood/tile surfaces, marble walls, framed glass, and house windows.

5.5 Finishing Cleaning

Once cleaning is complete, or if you wish to stop the robot, press the power button on the robot or the remote control. Wait for the suction to fully disengage before carefully removing the robot from the surface. Remember to remove the machine first before turning off the power completely.

6. Manutenzione

6.1 Cleaning Microfiber Cloths

After each use, remove the microfiber cleaning cloths from the robot. Wash them thoroughly with water and mild detergent. Allow them to air dry completely before storing or reusing. Using clean cloths is essential for optimal cleaning performance and to prevent streaks.

Image: High-density cleaning fiber cloth. Effective against dust, bacteria, dirt, oil, water stains, and guano. Add window detergent (not included) for best results.

6.2 Refilling Water Tank

Regularly check the water level in the 30ml tank. Refill as needed with clean water or a suitable window cleaning solution. Do not use corrosive liquids or solutions containing particles that could clog the spray nozzle.

6.3 Pulizia generale del robot

Pulisci l'esterno del robot con un panno morbido eamp cloth to remove any dust or residue. Ensure the suction ports and sensors are clean and unobstructed. Do not immerse the robot in water or spray water directly onto its electronic components.

7. Risoluzione Dei Problemi

Se riscontri problemi con il tuo LIECTROUX HCR-10, fai riferimento ai seguenti problemi comuni e alle relative soluzioni:

Se il problema persiste, contattare l'assistenza clienti.

8. Specifiche

9. Garanzia e supporto

For information regarding warranty coverage, please refer to the warranty card included with your product or contact the retailer where you purchased the LIECTROUX HCR-10. For technical support, troubleshooting assistance beyond this manual, or to inquire about replacement parts, please contact LIECTROUX customer service or your authorized dealer.
