SEESII M6 Combo Mini Chainsaw & Electric Pruning Shears Instruction Manual

1. Informazioni sulla sicurezza

Always prioritize safety when operating power tools. Read and understand all safety warnings and instructions before use. Keep this manual for future reference.

Precauzioni generali di sicurezza:

• Indossare adeguati dispositivi di protezione individuale (DPI), tra cui occhiali di sicurezza, guanti e protezioni acustiche.
• Assicurarsi che l'area di lavoro sia libera da astanti, in particolare bambini e animali domestici.
• Non utilizzare gli utensili in condizioni di umidità o in presenza di liquidi o gas infiammabili.
• Keep hands and body parts away from cutting blades and chains.
• Always remove the battery before performing any adjustments, changing accessories, or storing the tool.
• Use only original SEESII batteries and chargers.
• Conservare gli utensili in un luogo asciutto e sicuro, fuori dalla portata dei bambini.

Funzioni di sicurezza avanzate:

• Motosega: Features a dual-switch safety lock to prevent accidental startup.
• Forbici da potatura: Requires a double-trigger press for activation.
• Both tools are equipped with non-slip grips and protective scabbards for user safety.

2. Contenuto della confezione

The SEESII M6 Combo kit includes the following items:

• 1 mini motosega da 6 pollici
• 1 x forbici elettriche da potatura
• 2 x 2.0Ah Rechargeable Batteries
• 1 x caricabatterie rapido
• 2 x Chains (1 pre-installed on chainsaw)
• 1 x Sharpening Rod
• 1 x Empty Oil Bottle (Oil not included)
• 1 x paio di guanti
• 1 x Borsa portautensili
• 1 x chiave esagonale
• 1 x Cacciavite
• 1 x Manuale utente (questo documento)

Image: All components of the SEESII M6 Combo kit, including the mini chainsaw, pruning shears, batteries, charger, and accessories.

3. Impostazione

3.1 Ricarica e installazione della batteria

Before first use, fully charge both 2000mAh lithium batteries using the provided fast charger. Insert the charged battery firmly into the tool until it clicks into place.

3.2 Mini Chainsaw Chain Installation and Tensioning

One chain is pre-installed. If you need to replace or install a new chain:

1. Rimuovere la batteria dalla motosega.
2. Allentare la manopola del coperchio laterale e rimuovere il coperchio laterale.
3. Remove the old chain and guide bar if replacing.
4. Place the new chain onto the guide bar, ensuring the cutting teeth are facing the correct direction (refer to the arrow on the guide bar).
5. Attach the guide bar to the chainsaw and loop the chain around the sprocket.
6. Reinstall the side cover and lightly tighten the knob.
7. Check the chain slack. It should be 1-3 mm.
8. Turn the tensioning screw clockwise to tighten the chain until the slack is within the recommended range.
9. Fully tighten the side cover knob.

3.3 Electric Pruning Shears Blade Replacement

To replace the blade on the electric pruning shears:

1. Rimuovere la batteria dalle cesoie da potatura.
2. Loosen the screw with the large hex key, then loosen the screw with the small hex key.
3. Loosen the two mounting screws with a screwdriver.
4. Remove the rear cover and then carefully remove the old blades.
5. Place the new blades in position.
6. Insert the blade bolt and turn clockwise to tighten.
7. Align the screws with the hex holes and tighten clockwise with a hex key.
8. Stringere il dado.
9. Insert the screw and tighten clockwise.
10. Place the gasket and tighten the screw with a large hex key.

3.4 Electric Pruning Shears Blade Opening Adjustment

The pruning shears feature 3 adjustable cutting modes (15mm, 20mm, 30mm) for precise pruning:

1. Install the battery and press the power button to turn on the shears.
2. Quickly press the trigger twice until you hear two beeps and the blade opens to its maximum (30mm).
3. Press the power button to cycle through the cutting diameters (15mm, 20mm, 30mm). The LED indicators will show the selected mode.

4. Istruzioni per l'uso

4.1 Funzionamento della mini motosega

The 6-inch mini chainsaw is designed for efficient cutting of branches and logs up to 6 inches in diameter. It can cut a 6-inch branch in approximately 5-8 seconds with a chain speed of 23-26 ft/s.

1. Assicurarsi che la batteria sia completamente carica e installata correttamente.
2. Hold the chainsaw firmly with one hand, ensuring a stable grip on the non-slip handle.
3. Engage the dual-switch safety lock, then press the trigger to start the saw.
4. Position the chain against the branch to be cut and apply gentle, steady pressure. Allow the saw to do the work.
5. After cutting, release the trigger and engage the safety lock.

Image: A person demonstrating the use of the SEESII mini chainsaw for cutting logs.

4.2 Electric Pruning Shears Operation

The electric pruning shears are ideal for precise trimming of trees and flowers, with a maximum cutting diameter of 1.2 inches (30mm). The ultra-sharp SK5 high-carbon steel blade ensures clean cuts.

1. Assicurarsi che la batteria sia completamente carica e installata correttamente.
2. Turn on the shears by pressing the power button.
3. Quickly press the trigger twice to open the blades.
4. Adjust the cutting diameter as needed (15mm, 20mm, or 30mm) by pressing the power button.
5. Position the blades around the branch to be cut and press the trigger to make a clean cut.
6. The auto-lock mode conserves battery when not in active use.

Image: A person using the SEESII electric pruning shears to trim a tree branch, showing the adjustable cutting diameter.

5. Manutenzione

Una manutenzione regolare garantisce prestazioni ottimali e prolunga la durata dei tuoi utensili.

5.1 Pulizia

• Rimuovere sempre la batteria prima della pulizia.
• After each use, clean the blades of the pruning shears and the chain/guide bar of the chainsaw with a brush or cloth to remove sap, sawdust, and debris.
• Pulisci i corpi degli utensili con un pannoamp stoffa. Non utilizzare prodotti chimici aggressivi o detergenti abrasivi.

5.2 Lubrificazione

• Mini Chainsaw: Regularly lubricate the chain and guide bar using chain oil (not included, use the provided empty bottle for storage). Proper lubrication reduces friction and wear.
• Forbici elettriche da potatura: Apply a small amount of machine oil to the blade pivot point periodically to ensure smooth operation.

5.3 Blade and Chain Care

• Forbici da potatura: Sharpen the SK5 high-carbon steel blade as needed using the provided sharpening rod or a suitable sharpening tool. Replace blades when they become dull or damaged beyond sharpening.
• Mini Chainsaw: Keep the chain sharp for efficient cutting. Use the sharpening rod to maintain sharpness. Replace the chain if it becomes excessively dull, stretched, or damaged.

5.4 Conservazione

• Always remove batteries from the tools before storage.
• Store tools and batteries in a cool, dry place, away from direct sunlight and moisture.
• Use the provided tool bag for organized and protected storage.
• Ensure protective scabbards are on the chainsaw bar and pruning shears blades during storage.

6. Risoluzione Dei Problemi

Per i problemi più comuni e le possibili soluzioni, fare riferimento alla tabella sottostante.

7. Specifiche

8. Garanzia e supporto

SEESII provides exceptional after-sales support to ensure a worry-free purchase. If you have any questions or concerns regarding your SEESII M6 Combo Mini Chainsaw and Electric Pruning Shears, please do not hesitate to contact us.

Assistenza clienti:

• Disponibilità: 24/7 friendly customer service.
• Tempo di risposta: Our team aims to respond within 12 hours to quickly resolve any issues.
• E-mail: support@seesiius.com

For detailed warranty information, please refer to the warranty card included in your product packaging or visit the official SEESII websito.
