Codelocks KL1200 Slam Latch Instruction Manual

1. Introduzione

This manual provides detailed instructions for the installation, operation, and maintenance of the Codelocks KL1200 Slam Latch. Please read these instructions carefully before proceeding with installation or use to ensure proper function and longevity of your product.

2. Prodotto finitoview

The Codelocks KL1200 Slam Latch is designed for use with KL1200/CL1200 series locks, enabling a "push shut" locking mechanism for cabinets and lockers. This robust and durable latch eliminates the need to turn a handle to secure the door, offering convenience and security. It is suitable for both new installations and retrofits on wooden or steel lockers and cabinets, accommodating door thicknesses from 3mm (1/8") to 28mm (1 1/16"). The design is non-handed, simplifying installation.

3. Istruzioni per l'installazione

Refer to the exploded diagram below for component identification and assembly sequence.

Figura 1: Esploso view of the Codelocks KL1200 Slam Latch components. Key components include the main lock body, mounting plate (1), gaskets (2), slam latch mechanism, strike plate (4), and various screws (5, 6, 7).

1. Prepare the Door/Cabinet: Ensure the door or cabinet where the latch will be installed is clean and properly aligned. The latch is suitable for door thicknesses between 3mm (1/8") and 28mm (1 1/16").
2. Installazione della piastra di montaggio: Position the mounting plate (1) on the inside of the door/cabinet. Secure it using the appropriate screws (5, 6) as indicated in Figure 1. Ensure it is level and securely fastened.
3. Posizionamento della guarnizione: Place the gaskets (2) between the mounting plate and the slam latch mechanism. These gaskets help ensure a snug fit and protect the surfaces.
4. Slam Latch Mechanism Attachment: Align the slam latch mechanism with the mounting plate and gaskets. Insert the spindle (7) through the lock body and secure the slam latch mechanism to the mounting plate using the provided screws (indicated as '0' in the diagram, typically smaller screws).
5. Installazione della piastra di battuta: Identify the correct position for the strike plate (4) on the cabinet frame or adjacent door. The strike plate should align perfectly with the latch bolt when the door is closed. Mark and drill pilot holes, then secure the strike plate using its dedicated screws.
6. Regolazioni: Test the "push shut" locking action. If necessary, adjust the position of the strike plate or the main lock body to ensure smooth and secure engagement of the latch. The "Cutting links" (top right of diagram) may refer to adjustable spindle length for the main lock; ensure the spindle length is appropriate for your door thickness.

For detailed drilling templates or specific lock body installation, refer to the main KL1200 lock manual.

4. Istruzioni per l'uso

The Codelocks KL1200 Slam Latch operates with a simple "push shut" action.

• Chiudere a chiave: Simply close the cabinet or locker door. The slam latch mechanism will automatically engage with the strike plate, securing the door. No additional action, such as turning a handle, is required.
• Per sbloccare: Use the associated KL1200 lock to disengage the latch. Once unlocked, the door can be opened.

5. Manutenzione

Regular maintenance ensures the longevity and reliable operation of your slam latch.

• Pulizia: Wipe the latch and strike plate surfaces with a soft, damp panno. Evitare detergenti abrasivi o solventi, poiché potrebbero danneggiare la finitura.
• Ispezione: Periodically check all mounting screws for tightness. Loose screws can affect the latch's performance.
• Lubrificazione: If the latch mechanism feels stiff, a small amount of silicone-based lubricant can be applied to moving parts. Avoid oil-based lubricants as they can attract dust and debris.

6. Risoluzione Dei Problemi

If you encounter issues with your KL1200 Slam Latch, consider the following:

• Il fermo non si innesta:
  • Check alignment of the strike plate (4) with the latch bolt. Adjust if necessary.
  • Ensure the door closes fully and without obstruction.
  • Verify all mounting screws are tight.
• Door not staying closed:
  • Inspect the latch bolt and strike plate for wear or damage.
  • Confirm the latch mechanism is moving freely and not obstructed.
• Stiff operation:
  • Clean the mechanism to remove any accumulated dirt or debris.
  • Apply a silicone-based lubricant to the moving parts of the latch.

If problems persist, contact Codelocks customer support for further assistance.

7. Specifiche

8. Garanzia e supporto

For information regarding product warranty, technical support, or replacement parts, please visit the official Codelocks webo contattare direttamente il servizio clienti. Conservare la ricevuta d'acquisto come prova d'acquisto per eventuali reclami in garanzia.

Codelocks Official Websito: www.codelocks.com
