Simon Rack Advantage Metallic Shelving Unit

1. Introduzione

This manual provides instructions for the assembly, operation, and maintenance of your Simon Rack Advantage Metallic Shelving Unit, model ADVANTAGE 5/400. This unit is designed for storage purposes, featuring five metal shelves and a robust construction suitable for various environments such as garages or workshops. Please read these instructions carefully before assembly and use to ensure safe and efficient operation.

Image: Fully assembled Simon Rack Advantage Metallic Shelving Unit, showcasing il suo design e la sua struttura.

2. Informazioni sulla sicurezza

To prevent injury or damage to the shelving unit, observe the following safety guidelines:

• Non sovraccaricare gli scaffali. Each central shelf has a certified flex point load capacity of 75 kg (165 lbs). The top and bottom shelves can support up to 150 kg (330 lbs).
• Ensure the shelving unit is properly assembled according to the instructions to maintain stability.
• The unit is designed to be stable without wall anchoring when correctly assembled. However, for maximum safety, especially in areas prone to seismic activity or heavy traffic, consider anchoring the unit to a wall.
• All components are manufactured to European quality standards (EN 10130 DC 01 steel) to allow handling without risk of cuts or bumps.
• Tenere i bambini e gli animali domestici lontani dall'area di raccolta.

Image: Safety icon indicating that the product can be handled without risk of cuts or bumps.

3. Contenuto della confezione

Verificare che tutti i componenti siano presenti prima di iniziare il montaggio:

• 5 Metal Shelves (DC01 steel, 0.6 mm thickness)
• Acciaio Profiles (S325 steel, 1.5 mm thickness, Z275 galvanized coating)
• Viti per il montaggio
• 4 Plastic Feet (to prevent floor marking)
• Istruzioni di montaggio illustrate

4. Installazione e assemblaggio

Assembly of the Simon Rack Advantage shelving unit requires a flat key number 13. Follow the illustrated instructions provided in the package for step-by-step guidance. For visual assistance, assembly videos may be available on the manufacturer's websito.

Fasi di assemblaggio:

1. Disimballare tutti i componenti e verificarli rispetto all'elenco del contenuto della confezione.
2. Attach the plastic feet to the base of the vertical profiles.
3. Begin assembling the frame using the provided screws and a flat key number 13.
4. Install the metal shelves at your desired heights. The shelves are adjustable and can be distributed at different levels. The distance from the first tray to the floor is 20 cm.
5. The unit can be assembled to its full height or configured in an L-shape to optimize corner space.
6. Assicurarsi che tutte le viti siano serrate saldamente per garantire la massima stabilità.

Image: Illustrated guide for assembling the shelving unit, showing components and tools required.

Image: Visual representation of the tools required for assembly, including a wrench and hammer.

Opzioni di configurazione:

The shelving unit offers flexibility in configuration:

• Altezza completa: Assemble all five shelves vertically for maximum storage capacity.
• Forma a L: The unit can be split and configured into two smaller units, one of which can be used as a workbench, ideal for corner spaces.
• Livelli regolabili: Shelf heights are adjustable to accommodate items of various sizes.

Image: Diagram illustrating the option to convert the full-height shelving unit into two smaller units, one of which can serve as a workbench.

5. Istruzioni per l'uso

Once assembled, the Simon Rack Advantage shelving unit is ready for use. It provides free access to all shelves for convenient storage and retrieval of items.

Caricamento degli scaffali:

• Distribuire il peso in modo uniforme su ogni ripiano.
• Adhere to the maximum load capacities: 75 kg (165 lbs) for central shelves and 150 kg (330 lbs) for top and bottom shelves.
• The metal trays can be mounted on both sides, offering flexibility for different storage functions.

Image: Diagram illustrating the maximum load capacity of 75 kg (165 lbs) per shelf level.

Image: Visual representation of the adjustable height levels and the option to convert the unit into a workbench.

6. Manutenzione

To maintain the appearance and longevity of your shelving unit:

• Pulisci le superfici con la pubblicitàamp panno secondo necessità.
• Avoid using abrasive cleaners or harsh chemicals that could damage the powder-coated finish.
• Controllare periodicamente tutte le viti e i collegamenti per assicurarsi che siano sempre ben serrati.

7. Risoluzione Dei Problemi

If you encounter any issues with your shelving unit, consider the following:

• Instabilità: Ensure all screws are fully tightened and that the unit is placed on a level surface. Verify that the load on the shelves does not exceed the specified weight limits.
• Componenti danneggiati: If any part appears damaged upon arrival or during assembly, do not proceed with assembly. Contact customer support for assistance.

8. Specifiche

Image: Detailed diagram illustrating the dimensions (height, width, depth) and individual shelf load capacity of the shelving unit.

Image: Explanation of the 'Flex Point Certificate', demonstrating the shelf's ability to recover its original shape after load removal, contrasting with other manufacturers' shelves that may deform.

9. Garanzia e supporto

All Simon Rack products are manufactured in Spain and come with a Garanzia di 5 annoLa presente garanzia copre i difetti di fabbricazione in normali condizioni d'uso.

For warranty claims, technical support, or inquiries regarding your Simon Rack Advantage Metallic Shelving Unit, please contact your retailer or the manufacturer directly. Keep your proof of purchase for warranty validation.

Image: Certifications and warranty information, including a 5-year warranty, 'Made in Spain' origin, and ISO 9001:2015 quality certification.
