1. Introduzione
This manual provides comprehensive instructions for the installation, operation, and maintenance of your celexon Basic Motorized and Tensioned Projection Screen. Designed for optimal visual performance, this screen features a unique cord tension system that ensures a consistently flat and smooth projection surface, even after extended use. It is compatible with both 3D and 4K content, offering a superior viewing experience for home cinema, presentations, and more. The screen's black backing and black drop enhance contrast, delivering vibrant and sharp images.
2. Informazioni sulla sicurezza
- Leggere attentamente tutte le istruzioni prima dell'installazione e del funzionamento.
- Assicurarsi che l'alimentazione corrisponda al voltage requisiti specificati sull'etichetta del prodotto.
- Do not attempt to disassemble or repair the screen yourself. Refer all servicing to qualified personnel.
- Keep the screen away from direct sunlight, heat sources, and moisture.
- Ensure the mounting surface is strong enough to support the weight of the screen.
- Keep children and pets away from the screen during operation to prevent accidents.
- Avoid touching the screen surface with sharp objects or abrasive materials.
3. Contenuto della confezione
Si prega di controllare la confezione per verificare la presenza dei seguenti elementi:
- celexon Basic Motorized and Tensioned Projection Screen
- Telecomando
- Hardware di montaggio (viti, tasselli, staffe)
- Cavo di alimentazione
- Manuale dell'utente (questo documento)
If any items are missing or damaged, please contact celexon customer support.
4. Configurazione e installazione
The celexon Basic Motorized and Tensioned Projection Screen is designed for both wall and ceiling mounting. Follow these steps for a secure installation.
4.1 Screen Dimensions
The screen features a usable surface area of 240 x 135 cm (108 inches diagonal) with a 16:9 aspect ratio. The overall casing dimensions are approximately 275.9 cm (length) x 8 cm (height) x 11 cm (depth).
4.2 Istruzioni di montaggio
- Scegli la posizione: Select a suitable location on a wall or ceiling that can safely support the screen's weight (approximately 12.8 kg / 28.21 lbs). Ensure there are no electrical wires or pipes behind the drilling points.
- Segnare i punti di foratura: Using the provided mounting brackets as a template, mark the drilling points on the wall or ceiling. Ensure the points are level and correctly spaced.
- Fori di perforazione: Drill holes at the marked points using an appropriate drill bit for your wall/ceiling material. Insert wall anchors if necessary.
- Fissare le staffe: Securely fasten the mounting brackets to the wall or ceiling using the provided screws.
- Schermo di montaggio: Carefully lift the screen and attach it to the installed mounting brackets. Ensure it clicks securely into place.
- Connetti alimentazione: Plug the power cable into the screen's power input and then into a suitable power outlet.
5. Istruzioni per l'uso
Your celexon motorized screen is operated via the included remote control.
- Estendi schermo: Premere il tasto GIÙ button on the remote control to lower the screen. The screen will automatically stop when fully extended.
- Retract Screen: Premere il tasto UP button on the remote control to raise the screen. The screen will automatically stop when fully retracted.
- Stop Screen: Premere il tasto FERMARE button on the remote control to halt the screen at any desired position.
The integrated cord tension system ensures that the screen surface remains optimally flat and balanced during extension and retraction, providing a consistently smooth projection area.
6. Manutenzione
- Pulizia della superficie dello schermo: Utilizzare un morbido, damp cloth with mild soap and water to gently clean the screen surface. Do not use abrasive cleaners, solvents, or harsh chemicals, as these can damage the screen material. Allow the screen to air dry completely before retracting.
- Pulizia del Casing: Pulisci lo schermo casing con un secco o leggermente damp panno per rimuovere la polvere.
- Cura del motore: The motor is maintenance-free. Avoid obstructing the screen's movement or forcing it manually.
- Magazzinaggio: When not in use for extended periods, ensure the screen is fully retracted and stored in a dry, dust-free environment.
7. Risoluzione Dei Problemi
| Problema | Possibile causa | Soluzione |
|---|---|---|
| Lo schermo non risponde al telecomando. |
|
|
| Screen stops midway or moves erratically. |
|
|
| Screen surface appears wrinkled or uneven. |
|
|
8. Specifiche
| Caratteristica | Dettaglio |
|---|---|
| Marca | celexon |
| Modello | Basic Motorized and Tensioned Screen |
| Screen Dimensions (W x H) | Dimensioni: 240 x 135 cm |
| Dimensione diagonale | 108 pollici |
| Proporzioni | 16:9 |
| Dimensioni del prodotto (L x A) | 2.76m x 0.08m (casing) |
| Materiale | Polyester (screen surface) |
| Descrizione della superficie dello schermo | Bianco opaco |
| Guadagno | 0.9 |
| Viewangolo di ing | 150° |
| Tipo di montaggio | Montaggio a parete o a soffitto |
| Compatibilità | 3D and 4K UHD |
9. Garanzia e supporto
celexon products are manufactured to high quality standards. For information regarding warranty coverage and terms, please refer to the warranty card included with your product or visit the official celexon website. If you encounter any issues or require technical assistance, please contact celexon customer support through their official channels. Please have your product model and purchase details ready when contacting support.
