1. Informazioni sulla sicurezza
Before assembling, installing, or using this product, please read and understand all instructions carefully. Failure to follow these instructions can result in serious injury or death.
Importante avviso di sicurezza:
Ensure the pool is correctly assembled and regularly check the structure to prevent accidents. Adult supervision is required at all times when children are in or near the pool.
- Non lasciare mai i bambini incustoditi dentro o intorno alla piscina.
- Install fencing or approved barrier around the pool to prevent unsupervised access.
- Keep rescue equipment readily accessible.
- Non tuffarsi o saltare in piscina.
- Empty and store the pool properly during off-season to prevent water accumulation.
2. Prodotto finitoview
The Intex Ultra XTR Rectangular Tubular Pool Kit is designed for durability and ease of use, providing a robust and spacious swimming experience. It features a triple-layer liner for enhanced resistance and an improved structure for stability.
Image: The Intex Ultra XTR Rectangular Pool, showcasing its robust frame and spacious design.
Caratteristiche principali:
- Resistenza: Triple-layer liner for superior durability.
- Qualità: Enhanced liner and structure for long-lasting performance.
- Hydroaeration Installation: Easy assembly with robust metal tubes.
- Dimensioni: Approximately 7.32 x 3.66 x 1.32 meters (L x W x H).
- Ground Dimensions: 7.87 x 4.22 meters (L x W).
- Swimming Surface Dimensions: 7.03 x 3.30 meters (L x W).
- Capacità: 31,805 litri.
- Componenti inclusi: Sand filter pump (4m³/h), shut-off valves, safety ladder with removable steps, ground cloth, and pool cover.
3. Istruzioni per l'installazione
Proper site preparation and assembly are crucial for the stability and longevity of your Intex pool.
3.1 Preparazione del sito:
- Choose a firm, level surface free of sharp objects, debris, or excessive slopes.
- Ensure the chosen area is large enough to accommodate the pool's ground dimensions (7.87m x 4.22m) plus additional space for access and maintenance.
- Evitare di installare la piscina sotto linee elettriche aeree o vicino ad alberi che potrebbero far cadere foglie o detriti.
- Lay down the included ground cloth to protect the pool liner.
Image: The Intex pool set up in a garden, illustrating the required space and surrounding area.
3.2 Fasi di assemblaggio:
- Disimballare i componenti: Carefully unpack all parts and verify against the parts list in your separate assembly guide.
- Position Liner: Lay out the pool liner in the desired location on the prepared ground cloth. Ensure it is spread out smoothly without wrinkles.
- Montare il telaio: Insert the metal tubes into the liner sleeves and connect them according to the detailed instructions provided in the separate assembly manual. Ensure all connections are secure and locked into place.
- Installare la pompa del filtro: Connect the sand filter pump (SF80220RC-2, 4700 l/h) and shut-off valves as per the pump's specific instructions. Ensure all hoses are securely fastened to prevent leaks.
- Install Safety Ladder: Assemble and position the safety ladder with removable steps. Ensure it is stable and securely placed against the pool wall.
- Riempire la piscina: Begin filling the pool with water. As the water level rises, smooth out any remaining wrinkles in the liner from the center outwards.
Image: A family enjoying the Intex pool, demonstrating the pool's capacity and recreational use.
4. Istruzioni per l'uso
Once assembled and filled, your Intex pool is ready for use. Follow these guidelines for optimal operation.
4.1 Water Filling and Level:
- Fill the pool to the recommended water level, typically indicated by a fill line on the liner or approximately 6 inches from the top edge.
- The pool has a capacity of 31,805 liters. Filling time will vary based on water pressure.
4.2 Filtration System:
- The included sand filter pump has a flow rate of 4 m³/h (4700 l/h).
- Operate the filter pump daily to ensure proper water circulation and filtration. The duration of operation depends on pool usage and environmental conditions, typically 4-6 hours per day.
- Refer to the separate sand filter pump manual for detailed operating instructions, backwashing, and maintenance procedures.
Image: Children enjoying water activities in the Intex pool, highlighting its suitability for family recreation.
4.3 Pool Access:
- Always use the provided safety ladder for entering and exiting the pool.
- Remove the ladder steps when the pool is not in use to prevent unsupervised access, especially by young children.
5. Manutenzione
Una manutenzione regolare è essenziale per mantenere la piscina pulita, sicura e prolungarne la durata.
5.1 Water Chemistry:
- Test pool water regularly (daily or every other day) for pH, chlorine, and alkalinity levels.
- Adjust chemical levels as needed to maintain a balanced and sanitized pool environment.
- Consult a pool chemical guide for appropriate dosages and application methods.
5.2 Pulizia:
- Rasare quotidianamente la superficie per rimuovere foglie e detriti.
- Brush the pool walls and floor weekly to prevent algae growth and remove dirt.
- Aspirare il fondo della piscina secondo necessità per rimuovere i detriti depositati.
- Clean the filter pump's skimmer basket and pump strainer regularly.
5.3 Structural Integrity:
- Periodically inspect the pool frame, connections, and liner for any signs of wear, damage, or corrosion.
- Ensure all frame components are securely connected.
- Check for any leaks in the liner or connections and address them promptly.
Image: The Intex pool positioned in a beautiful outdoor landscape, emphasizing its aesthetic integration.
5.4 Winterization/Storage:
- At the end of the swimming season, thoroughly clean and dry all pool components.
- Disassemble the pool frame and liner according to the reverse of the assembly instructions.
- Store all parts in a dry, protected area, away from extreme temperatures and pests.
6. Risoluzione Dei Problemi
This section provides solutions to common issues you might encounter with your Intex pool.
| Problema | Possibile causa | Soluzione |
|---|---|---|
| L'acqua è torbida o verde. | Filtrazione insufficiente, equilibrio chimico inadeguato, crescita di alghe. |
|
| La pompa del filtro non funziona. | Power issue, clogged filter, air in system, motor malfunction. |
|
| Il livello dell'acqua sta scendendo. | Evaporazione, perdita nel rivestimento o nei collegamenti. |
|
| Telaio della piscina instabile. | Uneven ground, improper assembly, damaged frame components. |
|
7. Specifiche
Detailed technical specifications for the Intex Ultra XTR Rectangular Tubular Pool Kit.
| Caratteristica | Valore |
|---|---|
| Dimensioni del prodotto (L x P x A) | 7.32m x 3.66m x 1.32m |
| Ground Dimensions (L x W) | 7.87m x 4.22m |
| Swimming Surface Dimensions (L x W) | 7.03m x 3.30m |
| Numero di modello | 26364GN |
| Altezza | 132 centimetri |
| Lunghezza | 732 centimetri |
| Larghezza | 366 centimetri |
| Peso dell'articolo | 162.3 chilogrammi |
| Tipo di materiale | Cloruro di polivinile (PVC) |
| Capacità | 31805 litri |
| Colore | Grigio |
| Componenti inclusi | Sand filter SF80220RC-2 (4700 l/h, GS), safety ladder with removable steps (max. load 136 kg), ground protection sheet PE 75 g/m², polyethylene cover. |
| Assemblaggio richiesto | No (refers to the kit being complete, but assembly is required for setup) |
Image: Technical diagram showing the approximate dimensions of the Intex Ultra XTR pool.
8. Garanzia e supporto
For specific warranty information and customer support, please refer to the documentation included with your product or contact Intex directly.
- Politica di ritorno: This product typically has a 30-day return policy from the date of purchase.
- Supporto del produttore: For technical assistance, missing parts, or warranty claims, please visit the official Intex websito o contattare il loro servizio clienti.
- Puoi anche visitare il Intex Brand Store on Amazon for more product information and related items.
Image: Scan this QR code to discover the product in augmented reality. Access AR Experience
