Introduzione
This manual provides comprehensive instructions for the safe and efficient use of your Paulmann MaxLED 79797 RGBW Controller. This device allows you to control Paulmann MaxLED RGBW light strips, enabling functions such as switching, dimming, and changing light colors and effects via the included wireless remote control. The controller operates without requiring direct line-of-sight to the remote, offering a range of up to 30 meters.
Importanti istruzioni di sicurezza
- Leggere attentamente tutte le istruzioni prima dell'installazione e del funzionamento.
- Conservare questo manuale per riferimento futuro.
- Questo prodotto è progettato esclusivamente per uso interno (grado di protezione IP20). Non esporre a umidità o temperature estreme.
- Prima di qualsiasi intervento di installazione o manutenzione, assicurarsi che l'alimentazione elettrica sia scollegata.
- Only use with Paulmann MaxLED RGBW strips and compatible 24V power supplies.
- Do not attempt to open or modify the controller or remote control. This will void the warranty.
- Tenere le batterie fuori dalla portata dei bambini. Smaltire le batterie usate in modo responsabile.
Contenuto della confezione
Verificare che tutti i componenti siano presenti nella confezione:
- 1x Paulmann MaxLED RGBW Controller (Model 79797)
- 1x telecomando senza fili
- 1x Istruzioni di montaggio (questo manuale)
Image: The MaxLED RGBW Controller and its wireless remote control. The controller is a small white rectangular unit with a cable, and the remote is an oval-shaped white device with various buttons and a color wheel.
Image: Diagram showing the MaxLED RGBW Controller and remote control with their approximate dimensions. The controller measures 22.5x85x45mm and the remote 20x110x53mm. A 150mm cable connects the controller to the LED strip.
Configurazione e installazione
Follow these steps for proper installation of your MaxLED RGBW Controller:
- Preparare l'area di installazione: Ensure the surface where the LED strip will be mounted is clean, dry, and free of dust.
- Collegare la striscia LED: Connect your Paulmann MaxLED RGBW strip to the output cable of the controller. The system uses an easy plug-in connection. Ensure the connectors are securely fastened.
- Collegare l'alimentazione: Connect a compatible 24V Paulmann power supply (not included) to the input side of the MaxLED RGBW Controller.
- Montare il controller: The controller is designed for hidden installation. Place it in a discreet location where it is protected from physical damage and moisture, but still allows for proper signal transmission from the remote (up to 30m range).
- Accensione: Once all connections are secure, plug the power supply into a suitable electrical outlet.
- Pairing the Remote Control (if necessary): The remote control is usually pre-paired. If not, refer to the "Operating Instructions" section for pairing procedures.
Image: This image illustrates the MaxLED expandable component system, highlighting three key aspects: "Easy to connect" (showing a hand connecting an LED strip), "Easy to mount" (showing an LED strip being applied to a surface), and "Easy to control" (showing the remote control). This demonstrates the simplicity of the setup process.
Istruzioni per l'uso
The wireless remote control allows full command over your MaxLED RGBW strips.
Funzioni del telecomando:
Immagine: Un dettaglio view of the MaxLED RGBW remote control, showing its various buttons and the central color wheel. The remote features power, brightness, mode, speed, and color selection controls.
- Pulsante di accensione (O): Press to turn the LED strips On or Off.
- Controllo della luminosità (B +/-): Use the '+' button to increase brightness and '-' to decrease brightness.
- Ruota dei colori: Touch the color wheel to select a desired static color for your LED strips.
- Selezione della modalità (M): Cycle through various pre-programmed light effects and color changing modes.
- Controllo della velocità (S +/-): When in a dynamic mode, use the '+' button to increase the speed of the effect and '-' to decrease it.
Associazione del telecomando:
If your remote control is not responding, it may need to be paired with the controller:
- Assicurarsi che il controller sia acceso.
- Within 3 seconds of powering on the controller, press and hold the "Mode" (M) button on the remote control for a few seconds.
- The LED strips should flash to indicate successful pairing.
Manutenzione
Pulizia:
To clean the controller and remote control, gently wipe with a soft, dry cloth. Do not use abrasive cleaners, solvents, or excessive moisture, as this can damage the components.
Sostituzione della batteria del telecomando:
The remote control requires batteries (type not specified in product data, typically CR2032 or similar button cell). If the remote's range decreases or it stops responding, replace the battery:
- Individuare il vano batterie sul retro del telecomando.
- Open the compartment using a small screwdriver or by sliding the cover.
- Rimuovere la vecchia batteria e inserirne una nuova, assicurandosi della corretta polarità (+/-).
- Chiudere bene il vano batterie.
- Smaltire la vecchia batteria secondo le normative locali.
Risoluzione dei problemi
| Problema | Possibile causa | Soluzione |
|---|---|---|
| LED strips do not light up. | No power, loose connection, faulty power supply, remote not paired. | Check power supply connection. Ensure all cables are securely plugged in. Verify power outlet is functional. Re-pair the remote control (see Operating Instructions). |
| Il telecomando non risponde. | Dead battery, remote not paired, out of range. | Replace remote control battery. Re-pair the remote control. Move closer to the controller (within 30m). |
| I colori sono errati o incoerenti. | Loose connection to LED strip, faulty LED strip. | Check the connection between the controller and the LED strip. Ensure the strip is fully compatible. |
| Dimming or effects not working. | Remote control issue, incompatible LED strip. | Ensure the remote control battery is good and it is paired. Verify the LED strip is an RGBW dimmable type. |
Specifiche
| Marca | Paulmann |
| Numero di modello | 79797 |
| Dimensioni del prodotto (L x P x A) | 5.3 x 11 x 2 cm (Controller); 20 x 110 x 53 mm (Remote) |
| Peso | 102 grammi |
| Grado di protezione IP | IP20 (solo per uso interno) |
| Materiale | Plastica |
| massimo Wattage | 144 Watt |
| Voltage | 24 Volt |
| Tipo di sorgente luminosa | LED (for compatible strips) |
| Fonte di alimentazione | AC (via external 24V power supply) |
| Caratteristiche speciali | Dimmable, Variable Intensity, Remote Control, RGBW Color Change |
| Frequenza del telecomando | 2.4 GHz RF |
| Gamma di controllo remoto | Up to 30 meters (non-line-of-sight) |
| Batterie richieste (telecomando) | Sì (non incluso) |
Image: The MaxLED RGBW Controller and its remote control, emphasizing the 2.4 GHz RF wireless technology for reliable communication.
Garanzia e supporto
Garanzia:
Paulmann offers a 1-year availability for spare parts for this product. For specific warranty terms and conditions, please refer to the official Paulmann websito o contattare il rivenditore.
Assistenza clienti:
For further assistance, technical support, or inquiries regarding your Paulmann MaxLED RGBW Controller, please visit the official Paulmann website or contact their customer service department. Contact information can typically be found on the product packaging or the Paulmann websito.
Paulmann Websito: www.paulmann.com
