MasterPro Foodies Blender User Manual

1. Introduzione

This manual provides essential instructions for the safe and efficient operation of your MasterPro Foodies Blender. Please read it thoroughly before first use and retain it for future reference. The MasterPro Foodies Blender is designed for extracting juice from fruits and vegetables. It features a 350W motor, a 1700ml capacity, and two adjustable speeds. The appliance includes stainless steel blades and exterior for durability, and a non-stick spout for easy pouring. Its design allows for quick disassembly and cleaning.

Figure 1: MasterPro Foodies Blender with accompanying juice collection cup.

2. Importanti istruzioni di sicurezza

Quando si utilizzano apparecchi elettrici, è necessario adottare sempre le seguenti precauzioni di sicurezza di base per ridurre il rischio di incendi, scosse elettriche e/o lesioni alle persone, tra cui:

• Leggere tutte le istruzioni prima di mettere in funzione l'apparecchio.
• To protect against electrical hazards, do not immerse the motor base, power cord, or plug in water or other liquids.
• È necessaria un'attenta supervisione quando un elettrodomestico viene utilizzato da bambini o nelle loro vicinanze.
• Scollegare dalla presa quando non in uso, prima di montare o smontare componenti e prima di pulirlo.
• Non utilizzare alcun apparecchio con un cavo o una spina danneggiati, o dopo che l'apparecchio non funziona correttamente o è caduto o è stato danneggiato in qualsiasi modo.
• Use the appliance only on a stable, dry, and flat surface.
• Evitare il contatto con le parti in movimento.
• Non utilizzare l'apparecchio per scopi diversi da quello previsto.
• Prima di utilizzare il frullatore, assicurarsi che il coperchio sia ben chiuso in posizione.
• Non sovraccaricare l'apparecchio.
• Never put fingers or other objects into the feed tube while the appliance is operating. Always use the provided food pusher.

3. Componenti del prodotto

Familiarize yourself with the parts of your MasterPro Foodies Blender:

1. Base del motore: Contains the motor and control knob.
2. Juice Container/Pulp Container: Collects the processed pulp.
3. Filter Basket/Blade Assembly: Stainless steel filter and cutting blades for juice extraction.
4. Coperchio: Covers the juice container and has the feed tube.
5. Spingitore di cibo: Used to guide ingredients into the feed tube.
6. Beccuccio per il succo: Dispenses the extracted juice. Features a non-stick surface.
7. Bicchiere di succo: Raccoglie il succo fresco.

4. Installazione e assemblaggio

Prima del primo utilizzo, attenersi alla seguente procedura:

1. Disimballare: Rimuovere con attenzione tutti i componenti dalla confezione.
2. Pulito: Wash all removable parts (juice container, lid, food pusher, juice cup) with warm, soapy water. Rinse thoroughly and dry completely. The motor base should only be wiped with a damp stoffa.
3. Posizione Base: Place the motor base on a stable, dry, and flat surface.
4. Assemblaggio del contenitore: Place the juice container onto the motor base, ensuring it is seated correctly and clicks into place.
5. Inserisci filtro: Carefully insert the filter basket/blade assembly into the juice container. Ensure it is firmly in place.
6. Attacca il coperchio: Place the lid on top of the juice container. Secure the safety locking arm into position until it locks.
7. Place Juice Cup: Position the juice cup directly under the non-stick juice spout.

Figure 2: Assembled MasterPro Foodies Blender, ready for use.

5. Istruzioni per l'uso

Follow these steps to extract juice:

1. Collegamento elettrico: Ensure the blender is properly assembled and securely plugged into a suitable 220V power outlet.
2. Preparazione degli ingredienti: Wash fruits and vegetables thoroughly. Cut them into pieces small enough to fit comfortably into the 75mm wide feed tube. Remove any large seeds, pits, or hard skins.
3. Seleziona velocità: Turn the control knob on the motor base to the desired speed setting. Speed 1 is suitable for softer fruits and vegetables, while Speed 2 is recommended for harder ingredients.
4. Estrazione dei succhi: Gradually feed the prepared ingredients into the feed tube using the food pusher. Apply gentle, even pressure. Do not force ingredients or use fingers.
5. Collezione: The extracted juice will flow through the non-stick spout into the juice cup. Pulp will collect in the pulp container.
6. Completamento: Once juicing is complete, turn the control knob to '0' (off) and unplug the appliance from the power outlet.

Figure 3: MasterPro Foodies Blender in operation, extracting orange juice.

6. Manutenzione e pulizia

Regular cleaning ensures optimal performance and extends the life of your blender:

1. Scollegare: Scollegare sempre il frullatore dalla presa di corrente prima di pulirlo.
2. Smontare: Unlock the safety arm and carefully remove the lid, filter basket, and juice container from the motor base.
3. Lavare le parti rimovibili: Immediately after use, wash all removable parts (lid, food pusher, filter basket, juice container, juice cup) with warm, soapy water. Use a cleaning brush to thoroughly remove any pulp from the filter basket.
4. Risciacquare e asciugare: Rinse all parts thoroughly under running water and dry them completely before reassembly or storage.
5. Base del motore pulita: Pulisci l'esterno della base del motore con un pannoamp stoffa. Non immergere mai la base del motore in acqua o in altri liquidi.
6. Evitare abrasivi: Non utilizzare detergenti abrasivi, pagliette o prodotti chimici aggressivi, poiché potrebbero danneggiare le superfici.
7. Lavare solo a mano: All parts are designed for hand washing only. Do not place them in a dishwasher.

7. Risoluzione Dei Problemi

If you encounter issues with your MasterPro Foodies Blender, refer to the following common problems and solutions:

• Blender non si accende:
  • Assicurarsi che il cavo di alimentazione sia collegato saldamente a una presa elettrica funzionante.
  • Verify that the safety locking arm is correctly engaged and locked into position. The blender will not operate if it is not properly secured.
• Poor juicing performance or excessive vibration:
  • Assicurarsi che gli ingredienti siano tagliati nelle dimensioni adatte al tubo di alimentazione.
  • Do not overload the feed tube; feed ingredients gradually and apply gentle pressure with the food pusher.
  • Check if the filter basket is clean and free from clogs. A clogged filter can reduce efficiency.
  • Ensure the appliance is placed on a stable, flat, and level surface to minimize vibration.
• Leakage from the spout:
  • Confirm that all parts, especially the juice container and lid, are correctly assembled and securely fitted.
  • Avoid overfilling the juice container beyond its maximum capacity.

8. Specifiche

9. Garanzia e supporto

For detailed warranty information, product registration, or customer support, please refer to the documentation provided with your purchase. You may also visit the official MasterPro website for further assistance and contact options.
