SEVERIN HV 7157 2-in-1 Cordless Stick and Handheld Vacuum Cleaner User Manual

1. Introduzione

Thank you for choosing the SEVERIN HV 7157 2-in-1 Cordless Stick and Handheld Vacuum Cleaner. This appliance is designed for efficient and flexible cleaning of various surfaces. This manual provides essential information for the safe and effective use, maintenance, and troubleshooting of your vacuum cleaner. Please read these instructions carefully before first use and keep them for future reference.

2. Importanti istruzioni di sicurezza

Per evitare scosse elettriche, incendi o lesioni, osservare sempre le seguenti precauzioni di sicurezza:

• This appliance is intended for domestic use only. Do not use it outdoors or for commercial purposes.
• Non maneggiare la spina o l'apparecchio con le mani bagnate.
• Tenere capelli, abiti larghi, dita e tutte le parti del corpo lontano dalle aperture e dalle parti mobili.
• Do not vacuum up water, liquids, hot ashes, burning cigarettes, sharp objects, or flammable/combustible materials.
• Prima dell'uso, assicurarsi che il contenitore della polvere e il filtro siano installati correttamente.
• Utilizzare esclusivamente il caricabatterie originale fornito con l'apparecchio.
• Non tentare di riparare l'apparecchio da soli. Contattare il personale di assistenza autorizzato per le riparazioni.
• Conservare l'apparecchio in un luogo asciutto quando non viene utilizzato.

3. Contenuto della confezione

Si prega di verificare che tutti gli articoli siano presenti nella confezione:

• Main unit (integrated handheld vacuum)
• Removable XL aluminum suction tube (70 cm)
• S'Power high-speed motor brush with LED lighting
• 3-in-1 accessory kit (cushion brush, furniture brush, crevice tool)
• Montaggio a parete
• Caricabatterie
• Manuale d'uso

4. Prodotto finitoview

Familiarize yourself with the components of your SEVERIN HV 7157 vacuum cleaner:

Figura 1: The main handheld vacuum unit with dust container and handle.

Figura 2: The SEVERIN HV 7157 assembled as a cordless stick vacuum with the extension tube and motor brush.

• Unità principale: Contains the motor, dust container, and battery. Functions as a handheld vacuum.
• XL Suction Tube: Connects the main unit to the floor brush for stick vacuum operation.
• S'Power Motor Brush: Features a 2-in-1 brush roll with blue bristles for pet hair and red bristles for fine dust. Includes LED lighting for dark areas.
• Strumento accessorio 3 in 1: A versatile tool combining a crevice nozzle, cushion brush, and furniture brush for various cleaning tasks.
• Interruttore On/Off: Posizionato sull'impugnatura per un facile utilizzo.

5. Installazione e assemblaggio

Your SEVERIN HV 7157 can be used as a stick vacuum or a handheld vacuum.

5.1 Assemblaggio dell'aspirapolvere a stelo

1. Insert the XL aluminum suction tube into the main unit until it clicks securely into place.
2. Attach the S'Power motor brush to the other end of the XL suction tube, ensuring it clicks firmly.
3. Your stick vacuum is now ready for use.

5.2 Utilizzo come aspirapolvere portatile

To use the appliance as a handheld vacuum, simply detach the XL suction tube and motor brush from the main unit. You can then attach the 3-in-1 accessory tool directly to the main unit for targeted cleaning.

6. Carica della batteria

The SEVERIN HV 7157 is equipped with a modern Li-Ion battery (22.2 V/2200 mAh) that offers no memory effect and minimal self-discharge.

Figura 3: The vacuum cleaner charging while mounted on the wall.

1. Collegare il caricabatterie alla porta di ricarica sull'unità principale.
2. Collegare il caricabatterie a una presa a muro adatta.
3. The charging indicator light will illuminate to show that the battery is charging.
4. Una carica completa richiede circa 3 ore.
5. The battery features protection against overcharge and deep discharge.
6. For convenient storage and charging, use the provided wall mount.

7. Istruzioni per l'uso

Your vacuum cleaner offers flexible cleaning options.

7.1 Power On/Off and Suction Levels

• Press the On/Off switch on the handle to start the vacuum cleaner.
• The appliance has two power levels:
• Livello 1: Motor brush ON. Provides maximum runtime of approximately 25 minutes. Ideal for deep cleaning carpets and removing pet hair.
• Livello 2: Motor brush OFF. Provides maximum runtime of approximately 30 minutes. Suitable for hard floors and lighter debris.

7.2 Using the S'Power Motor Brush

The S'Power motor brush is designed for effective cleaning on both hard floors and carpets.

Figura 4: Close-up of the motor brush head showing the LED lighting for improved visibility.

• The brush roll features a 2-in-1 design: blue bristles for pet hair and red bristles for fine dust.
• The integrated LED lighting illuminates dark areas, such as under furniture, to ensure no dirt is missed.
• The 180° swivel joint allows for extremely flexible and easy maneuvering around obstacles and into tight spaces.

7.3 Handheld Vacuum Operation and Accessories

The integrated handheld vacuum is perfect for quick clean-ups and hard-to-reach areas.

Figura 5: Using the handheld vacuum to clean car seats effectively.

Figura 6: The handheld unit with an accessory tool cleaning an armchair.

Figura 7: Cleaning a surface with the handheld vacuum and brush attachment.

• Detach the main unit from the extension tube to use it as a handheld vacuum.
• Attach the 3-in-1 accessory tool directly to the main unit. This tool is ideal for cleaning cushions, furniture, and reaching into narrow crevices.

7.4 Cleaning Stairs and Elevated Surfaces

Figura 8: The stick vacuum configuration is suitable for cleaning stairs.

The lightweight and maneuverable design, combined with the 180° swivel joint, makes the HV 7157 suitable for cleaning stairs and other elevated surfaces with ease.

8. Manutenzione e pulizia

Una manutenzione regolare garantisce prestazioni ottimali e prolunga la durata del tuo aspirapolvere.

8.1 Svuotamento del contenitore della polvere

• The dust container has a capacity of 650 ml. Empty it regularly to maintain suction power.
• To empty, detach the dust container from the main unit.
• Open the container and dispose of the collected dust and debris.
• Close the container securely and reattach it to the main unit.

8.2 Pulizia del filtro HEPA

• The appliance is equipped with a HEPA filter, which should be cleaned periodically.
• Rimuovere il filtro dal contenitore della polvere.
• Tap the filter gently to remove loose dust. If necessary, rinse it under cold running water.
• Ensure the filter is completely dry before reinserting it into the vacuum cleaner. Do not use the appliance with a wet filter.

8.3 Cleaning the Motor Brush Roll

• The brush roll in the S'Power motor brush is removable for easy cleaning.
• Follow the instructions in the diagram (refer to product packaging or separate manual for visual guide) to unlock and remove the brush roll.
• Remove any tangled hair, threads, or debris from the brush roll.
• Reinsert the brush roll and lock it securely in place.

9. Risoluzione Dei Problemi

Se riscontri problemi con l'aspirapolvere, fai riferimento ai seguenti problemi comuni e alle relative soluzioni:

If the problem persists after trying these solutions, please contact Severin customer service.

10. Specifiche tecniche

11. Garanzia e supporto

Your SEVERIN HV 7157 vacuum cleaner comes with a standard manufacturer's warranty. Please refer to the warranty card included in your packaging for specific terms and conditions, including the warranty period and coverage details.

For technical support, spare parts, or warranty claims, please contact Severin customer service. Contact information can typically be found on the Severin websul sito o sulla confezione del prodotto.
