Manuale utente della scrivania elettrica regolabile in altezza Bush Business Furniture Move 60 Series da 48 pollici

1. Introduzione

This manual provides essential information for the safe and efficient use of your Bush Business Furniture Move 60 Series 48-inch Electric Height Adjustable Standing Desk. Please read these instructions thoroughly before assembly and operation to ensure proper functionality and longevity of your product.

2. Informazioni sulla sicurezza

• Assicurarsi che tutti i componenti siano fissati saldamente prima dell'uso.
• Do not exceed the maximum weight capacity of 200 pounds (90.7 kg) on the desktop.
• Durante la regolazione dell'altezza, tenere mani e oggetti lontani dalle parti in movimento.
• Utilizzare la scrivania solo su una superficie piana.
• Collegare il cavo di alimentazione da 10 piedi a una presa elettrica standard.
• Questo prodotto è progettato esclusivamente per uso interno.
• Avvertenza sulla Proposta 65: questo prodotto può esporvi a sostanze chimiche, tra cui la formaldeide, che lo Stato della California riconosce come cancerogena. Per ulteriori informazioni, visitare il sito www.P65Warnings.ca.gov.

3. Contenuto della confezione

Verificare che tutti i componenti siano presenti prima di iniziare il montaggio. La confezione include:

• 48W x 24D Electric Height Adjustable Standing Desk components
• Assembly hardware (Note: All assembly tools are not included.)
• Manuale di istruzioni

4. Installazione e assemblaggio

Assembly of the Move 60 Series desk is designed to be straightforward. It is recommended that two people assist with assembly for ease and safety.

assemblaggio finitoview

The desk features a durable thermally fused laminate desktop and a welded 16-gauge steel base for stability. Pre-drilled screw holes facilitate the assembly process.

Figura 1: Key features of the Move 60 Series desk, including the height range from 27 to 46.7 inches, the 16-gauge steel base, the up/down control with four programmable presets, and the wire management grommet.

Gestione dei cavi

The desktop includes a wire management grommet to help organize cables and maintain a tidy workspace.

Figura 2: Detail of the wire management grommet for organized cable routing.

5. Istruzioni per l'uso

The Move 60 Series desk allows for quick and easy transitions between sitting and standing positions.

Regolazione dell'altezza

The desk can be adjusted electrically from a minimum height of 27 inches (68.58 cm) to a maximum height of 46.7 inches (118.62 cm).

Figura 3: The simplified control panel for height adjustment.

To adjust the height, simply lift up or press down on the display button on the control panel. The desk will move smoothly to the desired height.

Preset Heights and Alerts

The control panel features customizable presets to save your preferred seated and standing heights. You can also set a custom alert to remind you to change positions throughout your workday.

Sensore anticollisione

For safety, the desk is equipped with an anti-collision sensor. If an object is detected during height adjustment, the desk's movement will stop automatically to prevent damage or injury.

Prodotto finitoview Video

For a visual demonstration of the Move 60 Series desk's features and operation, please watch the official product video below.

1 video: Un oltreview of the Bush Business Furniture Move 60 Collection, demonstrating the electric height adjustment and various desk configurations.

6. Manutenzione

Per mantenere l'aspetto e la funzionalità della tua scrivania, segui queste semplici istruzioni per la cura:

• Pulizia: Wipe the desktop and base with a damp cloth. Avoid harsh chemicals or abrasive cleaners that could damage the thermally fused laminate surface.
• Protezione della superficie: The laminate surface is scratch-resistant, but using coasters or desk pads can further protect it from spills and heavy objects.

7. Risoluzione Dei Problemi

If you encounter any issues with your Move 60 Series desk, refer to the following common solutions:

Scrivania che non regola l'altezza

• Check that the power cord is securely plugged into both the desk and a working electrical outlet.
• Ensure no objects are obstructing the desk's movement, triggering the anti-collision sensor.

Electronic Device Interference

Some sensitive electronic devices, such as graphics tablets, may experience electromagnetic interference (EMI) when placed directly above the control unit during desk movement. This can manifest as erratic cursor behavior or unexpected actions.

• Soluzione: To mitigate EMI, place a layer of aluminum foil between the sensitive device and the desk surface, directly above the control unit. Alternatively, reposition the device away from the control unit during height adjustments.

8. Specifiche

Detailed specifications for the Bush Business Furniture Move 60 Series 48-inch Electric Height Adjustable Standing Desk:

Figura 4: Dimensional drawing of the Move 60 Series desk.

9. Garanzia e supporto

Garanzia del produttore

This Bush Business Furniture Move 60 Series desk is backed by a Garanzia del produttore di 5 anniLa presente garanzia copre i difetti di materiali e di fabbricazione in normali condizioni di utilizzo.

Assistenza clienti

For warranty claims, replacement parts, or technical assistance, please contact Bush Furniture customer service. Refer to the contact information provided with your product packaging or visit the official Bush Furniture websito per i dettagli del supporto.
