Manuale utente della tastiera wireless ergonomica X9 Performance con trackball

1. Introduzione

Thank you for choosing the X9 Performance Ergonomic Wireless Keyboard with Trackball. This keyboard is designed to enhance your typing comfort and efficiency with its split ergonomic layout, integrated trackball, and convenient features. This manual provides detailed instructions to help you set up, operate, and maintain your new keyboard.

Image: The X9 Performance Ergonomic Wireless Keyboard with Trackball, showcasing its split design and integrated trackball.

2. Impostazione

2.1. Cosa c'è nella scatola

• X9 Performance Ergonomic Wireless Keyboard
• Adattatore wireless USB-A da 2.4 GHz
• Cavo di ricarica USB-C
• Manuale dell'utente (questo documento)

2.2. Collegamento della tastiera

The X9 Performance keyboard uses a 2.4GHz wireless connection via a USB-A adapter. No software installation is required for basic functionality.

1. Locate the USB-A wireless adapter. It is typically stored in a compartment on the underside of the keyboard for safekeeping.
2. Plug the USB-A wireless adapter into an available USB-A port on your computer (PC or Chrome device).
3. Turn on the keyboard using the power switch, usually located on the underside or side of the keyboard. The keyboard should automatically connect to your computer.

Image: The keyboard's underside showing the USB-A dongle storage and the USB-C charging port, highlighting its wireless and rechargeable capabilities.

2.3. Ricarica della tastiera

The keyboard features a built-in 2000mAh rechargeable battery. To charge:

• Connect the provided USB-C charging cable to the USB-C port on the keyboard.
• Connect the other end of the USB-C cable to a USB power source (e.g., computer USB port, USB wall adapter).
• The charging indicator light on the keyboard will illuminate during charging and turn off when fully charged. A full charge can provide up to 12 months of use.

3. Istruzioni per l'uso

3.1. Design ergonomico e comfort

The keyboard's split and sloped structure, combined with an integrated wrist rest, is designed to promote a natural hand and wrist posture, reducing strain during extended typing sessions.

Image: The keyboard's ergonomic split design and integrated wrist rest, illustrating how it promotes comfortable typing posture.

3.2. Integrated Trackball and Mouse Controls

The keyboard features a centralized trackball for thumb-controlled navigation, eliminating the need for a separate mouse. It includes dedicated mouse buttons and a scroll wheel.

• Sfera rotante: Use your thumb to control the cursor movement.
• Pulsante sinistro del mouse: Located to the left of the trackball.
• Pulsante destro del mouse: Located to the right of the trackball.
• Rotella di scorrimento: Positioned above the trackball for vertical scrolling.

Image: Close-up of the keyboard's central area, highlighting the thumb-controlled trackball for precise navigation.

Image: Diagram showing the scroll wheel, right click, left click, and trackball components on the keyboard.

3.3. Adjusting Trackball Sensitivity

You can fine-tune the trackball's cursor speed through your computer's operating system settings.

• Per PC Windows:
  1. Aprire Impostazioni.
  2. Vai a Bluetooth e dispositivi.
  3. Selezionare Topo.
  4. Regolare il Mouse pointer speed slider to your preferred sensitivity.

Image: Step-by-step visual guide on how to adjust trackball sensitivity within Windows settings.

3.4. Regolazione della retroilluminazione

The keyboard features white backlighting with 3 adjustable brightness levels for optimal visibility in various lighting conditions.

• To cycle through brightness levels (Off, Low, Medium, High), press the dedicated backlight control key (often indicated by a light bulb icon or similar).

Image: The keyboard with its white backlit keys illuminated, demonstrating visibility in a dim setting.

3.5. Tasti di scelta rapida

The keyboard includes 19 dedicated shortcut keys for quick access to various functions, such as volume control, media playback, and application management. Refer to the key legends for specific functions.

Immagine: una vista dall'alto view of the keyboard, pointing out the split 128-key layout, media keys, and 19 shortcut keys.

3.6. Prodotto finitoview Video

Guarda questo video ufficiale del prodotto per una panoramica visivaview of the X9 Performance Ergonomic Wireless Keyboard with Trackball, demonstrating its key features and benefits.

4. Manutenzione

4.1. Pulizia della tastiera

To ensure longevity and optimal performance, clean your keyboard regularly:

• Scollegare la tastiera dal computer prima di pulirla.
• Utilizzare un panno morbido e privo di lanugine leggermente dampcon acqua o una soluzione detergente delicata e non abrasiva.
• Evitare di spruzzare liquidi direttamente sulla tastiera.
• Per rimuovere polvere e detriti tra i tasti, utilizzare aria compressa.

4.2. Trackball Cleaning

If the trackball's movement becomes rough or inaccurate, it may need cleaning:

• Gently remove the trackball from its housing (refer to product diagrams if available for specific removal instructions).
• Clean the trackball and the inside of its housing, especially the small rollers or sensors, with a clean, lint-free cloth.
• Reinserire il trackball nel suo alloggiamento.

4.3. Cura della batteria

• Evitare di scaricare completamente la batteria frequentemente per prolungarne la durata.
• Quando non si utilizza la tastiera per lunghi periodi, conservarla in un luogo fresco e asciutto.

5. Risoluzione Dei Problemi

If you encounter issues with your X9 Performance keyboard, try the following solutions:

5.1. Keyboard Not Responding / Connectivity Issues

• Controlla la potenza: Ensure the keyboard is turned on and fully charged. Connect the USB-C charging cable to verify if the battery is low.
• Adattatore USB: Ensure the 2.4GHz USB-A adapter is securely plugged into a working USB port on your computer. Try a different USB port.
• Riparazione: If connection is lost, try unplugging and re-plugging the USB adapter. Turn the keyboard off and on again.
• Interferenza: Move the keyboard closer to the USB adapter or away from other wireless devices that might cause interference.

5.2. Trackball Not Moving Smoothly or Inaccurately

• Trackball pulito: Refer to Section 4.2 for trackball cleaning instructions. Dust or debris can affect performance.
• Regola la sensibilità: The trackball sensitivity might be too low or too high for your preference. Refer to Section 3.3 for instructions on adjusting trackball sensitivity in your operating system settings.

5.3. Retroilluminazione non funzionante

• Check Brightness Level: Press the backlight control key (often with a light bulb icon) to cycle through brightness levels and ensure it's not set to 'Off'.
• Livello della batteria: Ensure the keyboard has sufficient battery charge. Low battery might disable backlighting to conserve power.

6. Specifiche

Image: Technical drawing showing the dimensions of the X9 Performance Ergonomic Wireless Keyboard.

7. Garanzia e supporto

X9 Performance products are designed for reliability and performance. For specific warranty information regarding your keyboard, please refer to the warranty card included with your product or visit the official X9 Performance websito.

If you require technical assistance, troubleshooting, or have questions about your product, please contact X9 Performance customer support through their official channels. Contact information can typically be found on the product packaging or the brand's websito.
