7artisans 10mm F3.5 Ultra Wide Angle APS-C Mirrorless Lens Instruction Manual

1. Introduzione

Grazie per l'acquistoasing the 7artisans 10mm F3.5 Ultra Wide Angle APS-C Mirrorless Lens. This manual provides essential information for the proper use, maintenance, and care of your new lens. Please read it thoroughly before use to ensure optimal performance and longevity of the product.

Image 1.1: 7artisans 10mm F3.5 Lens Overview

2. Contenuto della confezione

Verifica che tutti gli articoli elencati di seguito siano inclusi nel tuo pacchetto:

• 7artisans 10mm F3.5 Lens x1
• Lens Front Cover x1
• Lens Back Cover x1
• Manuale utente x1
• Lens Packaging Box x1

Immagine 2.1: Contenuto della confezione

3. Componenti delle lenti

Familiarize yourself with the main components of your 7artisans 10mm F3.5 lens:

• Filter Installation Latch: For attaching filters.
• Anello di messa a fuoco: Utilizzato per regolare manualmente la messa a fuoco.
• Anello di apertura: Used to manually set the aperture (F3.5 to F16/F22).
• Attacco obiettivo: Collega l'obiettivo al corpo della fotocamera.
• Scala della profondità di campo: Provides a visual guide for depth of field at various apertures.

Image 3.1: Lens Structure and Components

4. Configurazione e installazione

To attach the 7artisans 10mm F3.5 lens to your Fuji X-mount camera:

1. Assicurati che la fotocamera sia spenta.
2. Remove the rear lens cap from the 7artisans lens and the body cap from your camera.
3. Align the red dot on the lens mount with the corresponding mark on your camera's lens mount.
4. Inserire delicatamente l'obiettivo nel supporto della fotocamera e ruotarlo in senso orario finché non scatta in posizione. Non forzare l'obiettivo.
5. Richiudere il tappo dell'obiettivo anteriore quando non lo si utilizza.

Compatible Fuji X-Mount Camera Models:

• X-H series: X-H1, X-H2, X-H2S, X-T5
• X-T series: X-T5, X-T4, X-T3, X-T2, X-T1, X-T50, X-T30, X-T30 II, X-T20, X-T200, X-T100
• X-S series: X-S10, X-S20
• X-PRO series: X-PRO2, X-Pro3
• X-E series: X-E4, X-E3, X-E2, X-E1
• X-A series: X-A1, X-A2, X-A3, X-A5, X-A7, X-A10, X-A20, X-M5

5. Utilizzo dell'obiettivo

5.1 Messa a fuoco manuale

This is a manual focus lens. Rotate the focusing ring to achieve sharp focus. Utilize your camera's focus peaking or magnification features for precise focusing, especially at wider apertures.

5.2 Controllo dell'apertura

The lens features a variable aperture from F3.5 to F22. Rotate the aperture ring to select your desired f-stop. A wider aperture (smaller f-number like F3.5) allows more light and creates a shallower depth of field, while a narrower aperture (larger f-number like F16/F22) allows less light, increases depth of field, and can produce a distinct 10-point starburst effect from bright light sources.

Image 5.1: Wide Focal Length, Not Fisheye

Image 5.2: Wide-angle Style Portrait

Image 5.3: Ten Needles of Brilliant Starlight

5.3 Non-Fisheye Wide-Angle Perspective

The 10mm focal length provides an ultra-wide field of view (109.5 degrees) without the typical distortion of a fisheye lens. This makes it suitable for architectural photography, landscapes, and creative portraits where straight lines and natural perspectives are desired.

Image 5.4: Straight Out Aesthetics

6. Manutenzione e cura

Una cura adeguata prolungherà la durata e le prestazioni delle tue lenti:

• Pulizia: Use a soft, clean microfiber cloth specifically designed for optics to clean the lens elements. For stubborn smudges, use a small amount of lens cleaning fluid applied to the cloth, not directly to the lens.
• Polvere: Use a blower brush to remove dust from the lens surface before wiping.
• Magazzinaggio: Store the lens in a dry, cool place away from direct sunlight and extreme temperatures. Always attach the front and rear lens caps when not in use.
• Evitare l'umidità: The lens is not water-resistant. Avoid exposure to rain, splashes, or high humidity.

7. Risoluzione Dei Problemi

Se riscontri problemi con l'obiettivo, tieni presente quanto segue:

• Immagini morbide: Ensure accurate manual focus. At wider apertures (e.g., F3.5), corners may exhibit some softness, which is common for ultra-wide lenses. Stopping down the aperture (e.g., to F5.6 or F8) can improve corner sharpness.
• Lens Flare/Ghosting: When shooting directly into strong light sources, some lens flare or ghosting may occur. This can be used creatively or minimized by adjusting your shooting angle or using a lens hood (if compatible).
• Correzione della distorsione: While designed to be non-fisheye, minor optical distortions can be further corrected in post-processing using a lens correction profile.

Correzione delle lenti File Utilizzo:

For optimal results, a lens correction file can be applied in post-processing software like Adobe Camera Raw or Lightroom. This helps to correct any minor optical distortions and chromatic aberrations.

• Windows Storage Path: C:Users\Administrator\AppData\Roaming\Adobe\CameraRaw\LensProfiles\1.0
• Mac OS Storage Path: Macintosh HD/Library/Application Support/Adobe/CameraRaw/LensProfilee/1.0

In CameraRaw, select "7artisans" for creation and "7artisans 10mm F3.5" for the model.

Image 7.1: Lens Correction Example

8. Specifiche

9. Garanzia e supporto

The 7artisans 10mm F3.5 lens comes with a Garanzia di 1 anno dalla data di acquisto. Conservare la prova d'acquisto per eventuali reclami in garanzia.

For further assistance, technical support, or warranty inquiries, please visit the official 7artisans store or contact their customer service:
