1. Introduzione e oltreview
The SmallRig RS20 Mini Camera Flash is a compact and powerful GN12 speedlite designed for mirrorless cameras, offering professional-grade lighting in a portable form factor. It features a built-in 2000mAh battery, an intuitive OLED screen for precise control, and rapid recycling times, making it ideal for various photography scenarios.
Le caratteristiche principali includono:
- Pro-Brightness in Palm Size: Delivers 200W COB Light-equivalent output at only 4.5oz (128g).
- Batteria a lunga durata: 2000mAh lithium battery supports 500+ flashes at maximum power, with a 3-hour full charge time via USB-C.
- Fast Recycling Time: Achieves 0.1s recycle at minimum power and 1.8s at full burst.
- OLED Display Precision Control: Intuitive interface with 8 power levels and 22 steps (1/1 to 1/128 plus 0.3-step fine-tuning).
- Universal Hot Shoe Compatibility: Mounts directly onto mirrorless cameras from Canon, Sony, Nikon, Fujifilm, and Olympus without adapters.
- Wireless Multi-Flash Sync: Supports advanced optical synchronization for professional lighting setups.
2. Cosa c'è nella scatola
Verificare che tutti i componenti siano presenti nella confezione:
- Flash x 1
- Cavo di ricarica USB-C x 1
- Borsa di stoccaggio x 1
- Istruzioni per l'uso x 1
3. Impostazione
3.1 Caricamento della batteria
Before first use, fully charge the built-in 2000mAh lithium battery. Use the provided USB-C charging cable and connect it to a 5V 1A power source. A full charge typically takes approximately 3 hours.
3.2 Montaggio del Flash
The SmallRig RS20 Mini Flash is designed with a universal single contact hot shoe, ensuring broad compatibility with most mirrorless cameras from brands like Canon, Sony, Nikon, Fujifilm, and Olympus.
- Assicurati che la fotocamera sia spenta.
- Slide the hot shoe mount of the RS20 flash into your camera's hot shoe slot until it clicks securely into place.
- Ensure the flash is firmly seated to maintain a stable connection.
4. Istruzioni per l'uso
4.1 Accensione/spegnimento
Locate the power switch on the side of the flash unit. Slide it to the 'ON' position to power on the device. Slide it to the 'OFF' position to power off.
4.2 Regolazione dei livelli di potenza
The RS20 features an intuitive OLED display for precise control over flash output. It offers 8 power levels and 22 steps, ranging from 1/1 (full power) to 1/128, with 0.3-step fine-tuning capability.
- Use the 'MODE' button to cycle through available modes (e.g., Manual, Optical Slave).
- Use the '+' and '-' buttons to adjust the flash power output according to your lighting needs. The OLED screen will display the current power setting.
4.3 Recycling Time
The RS20 Mini Flash boasts a fast recycling time, allowing for rapid consecutive shots. It can recycle in 0.1 seconds at minimum power and 1.8 seconds at full power, enabling the capture of up to 8 photos within 3 seconds.
4.4 Wireless Multi-Flash Sync
The RS20 supports advanced optical synchronization, allowing you to build professional multi-flash lighting setups. You can designate units as transmitters or responders for complex lighting scenarios such as 3-point studio portraiture or 360° product shoots.
5. Manutenzione
To ensure the longevity and optimal performance of your SmallRig RS20 Mini Camera Flash, follow these maintenance guidelines:
- Pulizia: Use a soft, dry cloth to wipe the exterior of the flash. For stubborn dirt, slightly dampen the cloth with water. Avoid using strong detergents or solvents.
- Magazzinaggio: Quando non lo si utilizza, riporre il flash nella custodia fornita in dotazione, in un luogo fresco e asciutto, lontano dalla luce solare diretta e da temperature estreme.
- Cura della batteria: If storing for extended periods, charge the battery to approximately 50% every three months to preserve battery health.
- Evitare l'impatto: Proteggere il flash da cadute e urti che potrebbero danneggiare i componenti interni.
6. Risoluzione Dei Problemi
If you encounter issues with your SmallRig RS20 Mini Camera Flash, refer to the following common problems and solutions:
| Problema | Possibile causa | Soluzione |
|---|---|---|
| Il flash non si accende. | La batteria è scarica o non carica. | Charge the flash using the USB-C cable. Ensure the power switch is in the 'ON' position. |
| Il flash non si attiva. | Incorrect mounting or poor hot shoe contact. Flash is in an incompatible mode. | Ensure the flash is securely mounted on the camera's hot shoe. Check the flash mode settings on the OLED display. |
| Slow recycling time. | Battery is low. Flash is set to full power. | Recharge the battery. Reduce the flash power output. |
| Il display OLED è vuoto o non risponde. | Malfunzionamento del dispositivo. | Try powering the unit off and on again. If the issue persists, contact customer support. |
Se il problema persiste dopo aver provato queste soluzioni, contattare l'assistenza clienti SmallRig per ulteriore assistenza.
7. Specifiche
Detailed technical specifications for the SmallRig RS20 Mini Camera Flash (Model: 5374):
| Specificazione | Valore |
|---|---|
| Dimensioni del prodotto | 2.8 x 2.9 x 1.8 pollici (46.0 × 71.0 × 73.0 mm) |
| Peso dell'articolo | 4.5 once (128.0 ± 5.0 g) |
| Numero di modello | 5374 |
| Tipo di batteria | Batteria non standard (inclusa) |
| Capacità della batteria | 3.7 V 2000 mAh |
| Potenza di carica | 5V 1A |
| Tempo di ricarica | 3 ore |
| Flash Count (Max Power) | 500 scatti |
| Recycle Time (Max Power) | 1.8 secondi |
| Power Adjustment Levels | 8 fermate (da 1/1 a 1/128) |
| Numero guida | GN12 |
| Temperatura del colore | 6500K |
| Velocità di sincronizzazione massima | 1/250 secondo |
| Supporti compatibili | Universal Hot Shoe Mount |
| Materiale | Plastica ABS |
8. Garanzia e supporto
SmallRig products are designed for reliability and performance. For warranty information and customer support, please refer to the official SmallRig webo contattare direttamente il servizio clienti. Conservare la ricevuta d'acquisto come prova d'acquisto per eventuali reclami in garanzia.
