Olvy Portable Air Compressor User Manual

Introduzione

Thank you for choosing the Olvy Portable Air Compressor. This device is designed for convenient and efficient inflation of various items, including car, bike, and motorcycle tires, as well as sports balls and inflatable mattresses. Its cordless design, powerful rechargeable battery, and smart features make it an essential tool for on-the-go inflation. Please read this manual carefully before use to ensure proper operation and to maximize the product's lifespan.

Informazioni sulla sicurezza

• Tenere sempre il dispositivo lontano dalla portata dei bambini.
• Non utilizzare il compressore in condizioni di umidità o in prossimità di liquidi o gas infiammabili.
• Assicurarsi che la pressione impostata per l'articolo da gonfiare sia corretta, per evitare un gonfiaggio eccessivo che potrebbe causare danni o lesioni.
• Non lasciare il compressore incustodito durante il funzionamento.
• Dopo un uso prolungato, lasciare raffreddare il dispositivo per evitare il surriscaldamento.
• Utilizzare solo i cavi di ricarica e gli adattatori forniti.
• Non smontare o modificare il dispositivo. Contattare l'assistenza clienti per le riparazioni.

Contenuto della confezione

Verificare che tutti gli articoli siano presenti nella scatola:

• 1x Olvy Portable Air Compressor
• 1x cavo di ricarica USB-C
• 1x 12V Car Charger
• 3x Valve Adapters (Presta, Ball Needle, Inflatable Nozzle)
• 1x Waterproof Storage Pouch
• 1x Manuale utente

The image above displays the complete set of items you should find in your product box, ensuring you have everything needed for various inflation tasks.

Caratteristiche del prodotto

• Design senza fili e portatile: Compact 12V air compressor with an integrated 6000 mAh rechargeable battery for inflation anywhere without an electrical outlet.
• Prestazioni ad alta pressione: Delivers up to 10.3 bar / 150 PSI with a flow rate of 28 L/min.
• Spegnimento automatico: Prevents over-inflation by stopping automatically once the preset pressure is reached.
• Multi-Adapter Compatibility: Includes 4 nozzles/adapters suitable for car tires, bike tires, balls, inflatable mattresses, and other inflatables.
• Display digitale intelligente: LCD screen shows pressure in PSI, BAR, KPA, or KG/cm² for precise monitoring during inflation.
• Torcia LED integrata: Features an LED light with an SOS mode for emergencies or low-light conditions.
• Funzione banca di potere: Can be used to charge other devices via its USB output.
• Sistema di raffreddamento: Built-in system to prevent overheating during extended use.

This image highlights the versatility of the digital display, allowing users to select their preferred pressure unit, and also shows the included storage pouch for convenient transport and protection.

The compressor's multi-functional design allows it to serve as an air pump, a portable power bank for charging electronic devices, and a flashlight with both steady and flashing (SOS) modes for enhanced utility.

With its substantial 6000 mAh battery, the compressor is capable of inflating a wide range of items, from vehicle tires to sports equipment, making it a versatile tool for many applications.

Per iniziare (installazione)

1. Caricamento del compressore

Before first use, fully charge the compressor. Connect the provided USB-C cable to the charging port on the device and the other end to a USB power adapter (not included) or use the 12V car charger. The digital display will indicate the charging status. A full charge ensures optimal performance and battery life.

2. Comprensione del display e dei controlli

The digital display shows the current pressure and allows you to set target pressure. The control buttons typically include:

• Pulsante di accensione: Accende/spegne il dispositivo.
• Pulsante Unità: Cycles through pressure units (PSI, BAR, KPA, KG/cm²).
• Pulsanti '+' / '-': Adjusts the target pressure.
• Pulsante luce: Activates the LED flashlight and SOS mode.
• Mode Button (often indicated by vehicle/ball icons): Selects preset inflation modes for different items (e.g., car, bike, motorcycle, ball).

Istruzioni per l'uso

1. Preparing for Inflation

1. Attiva: Press the power button to turn on the compressor. The digital display will light up.
2. Seleziona unità: Press the 'Unit' button to choose your desired pressure unit (PSI, BAR, KPA, or KG/cm²).
3. Imposta la pressione target: Use the '+' and '-' buttons to set the desired pressure for your item. Refer to the item's manufacturer recommendations for correct pressure.
4. Collegare l'ugello: Select the appropriate valve adapter and securely attach it to the item's valve. Then, connect the compressor's hose to the adapter.

2. Avvio e arresto dell'inflazione

1. Inizia l'inflazione: Once the target pressure is set and the nozzle is connected, press the power button again to start inflation. The compressor will begin to pump air, and the display will show the real-time pressure.
2. Spegnimento automatico: Il compressore si arresterà automaticamente una volta raggiunta la pressione target preimpostata.
3. Arresto manuale: You can manually stop inflation at any time by pressing the power button.
4. Disconnetti: Carefully disconnect the hose from the valve and the adapter from the item.

This visual guide demonstrates the straightforward process of setting the desired pressure, connecting the valve, and initiating inflation, highlighting the convenience of the automatic shut-off feature.

3. Using the LED Light and SOS Mode

Press the 'Light' button once to turn on the LED flashlight. Press it again to activate the SOS flashing mode. Press a third time to turn off the light. This feature is useful for nighttime emergencies or working in dark environments.

4. Utilizzo come Power Bank

To use the compressor as a power bank, connect your device (e.g., smartphone) to the USB output port on the compressor using your device's charging cable. The compressor's battery will then charge your device.

Manutenzione

• Pulizia: Pulire l'esterno del compressore con un panno morbido eamp panno. Non utilizzare prodotti chimici aggressivi o detergenti abrasivi. Assicurarsi che il dispositivo sia spento e scollegato da qualsiasi fonte di alimentazione prima di pulirlo.
• Magazzinaggio: Store the compressor in its waterproof storage pouch in a cool, dry place, away from direct sunlight and extreme temperatures.
• Cura della batteria: Per prolungare la durata della batteria, caricare il compressore almeno una volta ogni tre mesi, anche se non lo si utilizza. Evitare di scaricare completamente la batteria frequentemente.
• Tubo flessibile e adattatori: Inspect the inflation hose and adapters regularly for any signs of wear or damage. Replace if necessary to ensure proper sealing and performance.

Risoluzione dei problemi

Specifiche

Garanzia e supporto

Olvy products are manufactured to high-quality standards. For warranty information, please refer to the documentation provided with your purchase or contact Olvy customer support. If you encounter any issues or have questions regarding your Olvy Portable Air Compressor, please reach out to our customer service team for assistance. Contact details can typically be found on the product packaging or the official Olvy websito.
