EF ECOFLOW DELTA 3 Classic Portable Power Station

1. Introduzione

The EF ECOFLOW DELTA 3 Classic is a portable power station designed to provide reliable power for various applications, including home backup, outdoor activities, and emergency situations. Featuring a 1024Wh LiFePO4 battery and 1800W AC output (3600W surge with X-Boost), it offers versatile charging options and smart control capabilities.

Image: The DELTA 3 Classic is designed for portability, shown here being carried in an outdoor setting. Its compact size (15.7 x 7.9 x 11.1 inches) and weight (26.7 lbs) make it easy to transport.

2. Istruzioni di sicurezza

Please read and understand all safety instructions before operating the DELTA 3 Classic. Failure to follow these instructions may result in electric shock, fire, or serious injury.

• Do not expose the unit to water, rain, or moisture.
• Do not use the unit near heat sources or in direct sunlight for extended periods.
• Ensure adequate ventilation during use to prevent overheating.
• Do not disassemble, repair, or modify the unit. Contact authorized service personnel for repairs.
• Tenere fuori dalla portata dei bambini e degli animali domestici.
• Utilizzare solo accessori e cavi di ricarica approvati.
• Evitare di far cadere l'unità o di sottoporla a forti urti.

3. Cosa c'è nella scatola

The standard package for the EF ECOFLOW DELTA 3 Classic includes the following items:

• EF ECOFLOW DELTA 3 Classic Portable Power Station
• Cavo di ricarica CA.

Please check all components upon unpacking. If any items are missing or damaged, contact customer support.

4. Caratteristiche del prodotto

The DELTA 3 Classic is equipped with advanced features for optimal performance and user convenience:

• Uscita ad alta potenza: Delivers 1800W AC output (3600W surge) with X-Boost technology, capable of powering a wide range of appliances.
• Ricarica ultraveloce: Recharges from 0% to 80% in just 45 minutes via X-Stream AC charging.
• Gruppo di continuità (UPS): Automatically switches to battery power in under 10ms during outages, proteggendo i dispositivi elettronici sensibili.
• Batteria LiFePO4: Features durable LiFePO4 battery cells with a 10+ year lifespan and an EV-grade CTC design.
• Controllo intelligente delle app: Monitor usage, set charging schedules, and activate backup modes via the EcoFlow app.
• Funzionamento silenzioso: Operates at a low noise level, as quiet as 30 dB when powering under 600W.

Image: The DELTA 3 Classic operates quietly, with noise levels as low as 30 dB when powering devices under 600W, comparable to a quiet library.

5. Impostazione

Follow these steps for initial setup of your DELTA 3 Classic:

1. Disimballare: Estrarre con cautela la centrale elettrica e tutti gli accessori dall'imballaggio.
2. Carica iniziale: Before first use, fully charge the DELTA 3 Classic using the provided AC charging cable. Plug the AC cable into the unit's AC input port and then into a standard wall outlet. The display will show charging progress.
3. Accensione: Tenere premuto il pulsante di accensione principale per alcuni secondi finché il display non si illumina.

6. Istruzioni per l'uso

6.1 Charging the DELTA 3 Classic

The DELTA 3 Classic offers multiple charging methods:

• Ricarica CA: Connect the AC charging cable to a wall outlet. The X-Stream technology allows for 0-80% charge in approximately 45 minutes.
• Ricarica solare: Connect compatible solar panels (sold separately) to the solar input port. The unit can recharge in approximately 2.5 hours with a 500W solar panel.
• Carica dell'alternatore: Charge from your vehicle's alternator using an appropriate cable (sold separately). This method can achieve 0-80% in about 1.8 hours with a 500W alternator charger.
• Ricarica del generatore: The unit can also be charged via a generator.

Image: The DELTA 3 Classic supports four charging methods: X-Stream AC, Solar, Generator, and Alternator, providing flexibility for various situations.

6.2 Utilizzo delle porte di uscita

The DELTA 3 Classic provides various output ports to power your devices:

• Prese CA (x3): Provides up to 1800W total AC power. Press the AC power button to enable/disable AC output.
• Porte USB-C (x2): One 100W Max USB-C port and one 30W Max USB-C port for fast charging compatible devices.
• Porta USB-A (x1): Provides up to 18W Max for standard USB devices.

Image: The DELTA 3 Classic features six versatile output ports, including three AC outlets, two USB-C ports, and one USB-A port, for diverse charging needs.

6.3 X-Boost Technology

The X-Boost feature allows the DELTA 3 Classic to power devices requiring up to 2600W by lowering the voltage and current, enabling it to run higher-wattage appliances safely. This feature is automatically enabled when the output exceeds 1800W.

Image: The DELTA 3 Classic provides 1800W AC output with a 3600W surge capability via X-Boost, suitable for various household appliances and electronics.

6.4 Funzione di alimentazione ininterrotta (UPS)

When connected to a wall outlet and powering devices, the DELTA 3 Classic acts as an Uninterruptible Power Supply. In the event of a power outage, it automatically switches to battery power in less than 10 milliseconds, ensuring continuous operation for connected electronics like computers and servers.

Image: The DELTA 3 Classic's UPS function ensures zero interruptions, automatically switching to battery power within 10 milliseconds during a power loss.

6.5 Controllo intelligente dell'app

Download the EcoFlow app to manage your DELTA 3 Classic remotely. The app allows you to:

• Monitor power usage and battery status.
• Set charging and discharging parameters.
• Activate backup modes like Storm Alert or Self-Powered Mode.
• Ricevi aggiornamenti del firmware.

Image: The EcoFlow app provides deeper insights and easier control, allowing users to monitor energy usage and schedule tasks from their smartphone.

6.6 Video ufficiale del prodotto

Video: Un video ufficiale del prodotto mostraasing the EF ECOFLOW DELTA 3 Classic Portable Power Station, highlighting its features and applications.

7. Manutenzione

Proper maintenance ensures the longevity and performance of your DELTA 3 Classic:

• Magazzinaggio: Store the unit in a dry, well-ventilated area, away from direct sunlight and extreme temperatures. For long-term storage, charge the battery to 50-80% every 3-6 months.
• Pulizia: Utilizzare un panno asciutto e morbido per pulire l'esterno dell'unità. Non utilizzare prodotti chimici aggressivi o materiali abrasivi.
• Cura della batteria: Avoid fully discharging the battery frequently. Regular partial discharges and recharges are beneficial for LiFePO4 batteries.

Image: The internal structure of the DELTA 3 Classic, highlighting its automotive-grade full-tab LFP cells, designed for efficiency and durability with a 10-year lifespan.

8. Risoluzione Dei Problemi

If you encounter issues with your DELTA 3 Classic, refer to the following common problems and solutions:

For further assistance, please contact EF ECOFLOW customer support.

9. Specifiche

10. Garanzia e supporto

The EF ECOFLOW DELTA 3 Classic comes with a manufacturer's warranty. Please refer to the warranty card included with your product or visit the official EF ECOFLOW websito per termini e condizioni di garanzia dettagliati.

For technical support, troubleshooting assistance, or warranty claims, please contact EF ECOFLOW customer service through their official websito o le informazioni di contatto fornite nella documentazione del prodotto.

Risorse online:

• Visita il sito ufficiale EF ECOFLOW Store on Amazon per ulteriori prodotti e informazioni.
